KZ25 25W 4A USB Intelligent Trigger Electronic Load Fast Charge Tester Voltmeter Battery Capacity Tester

Features: This product can be used as a normal electronic load or as a USB electronic load. QC2.0/QC3.0/AFC/FCP fast charge protocol, trigger output 5V/9V/12V/20V and other voltages; LCD display, friendly human-computer interface and excellent performance indicators to meet diversified Test requirements. Load Function: 1. Can display current A, voltage V, power W, capacity Ah, and discharge time; 2. Has a sound protection mechanism; 3. Automatic calculation of discharge capacity and discharge time; 4. Set maximum discharge capacity (OAH) and maximum discharge time (OHP); (to achieve unattended power aging test) 5. Intelligent temperature control fan, when the power is greater than 10W or the temperature is greater than 40 C, the fan automatically starts; 6. Rotary coded potentiometer can accurately adjust the current to 0.01A, the current can be locked to prevent misoperation; 7. It is possible to set the load to resume normal operation (REC) after the protection mechanism is released. 8. Data group function: You can choose whether to add one-stage capacity value and running time. Trigger/Cheat Function: 1. Trigger function: The charger can be used for QC2.0, QC3.0, AFC 9V, FCP, and multiple fast charging modes for deception triggering. 2. Fast charge support automatic detection function: Press and hold the trigger button TRG to detect the charger's support for the fast charge mode. 3. Power-on automatic trigger fast charge function: Power-on automatically triggers fast charge (setting in AUTO: ON state) which is suitable for batch testing of aging chargers. Specification: Types: KZ25 Rated operating voltage: DC4.0-25.0V (with anti-reverse protection, reverse connection does not burn) Maximum discharge power: 25W Rated operating current: 0.03-4.00A Maximum fan speed: With oil bearing bearing wind 580010%RPM, Fast charge trigger mode: QC2.0 5V 9V 12V 20V, QC3.0, AFC9V, FCP Constant current accuracy: (1%+3 words) Voltage accuracy: (0.5%+3 words) Cooling method: Intelligent temperature control fan + all aluminum heat sink Working environment temperature: -20-40C Expansion interface: Micro USB interface, Type-C interface Overvoltage protection (OVP):Default 5.10A (can be set by yourself) Over power protection (OPP): Default 25.5W (can be set by yourself) Undervoltage protection (LVP): Default 4.0V (can be set by yourself) Over temperature protection (OTP): Default 80C or so (cannot be set) Dimensions: 4.6x10cm/1.81x3.94inch Package Includes: 1 x KZ25 USB Intelligent Trigger Electronic Load Tester More document click to download: KZ2535 If you want to buy KZ35,please click to buy:1444154
