KTNNKG 6PCS 220V Single-channel LED Remote Control Switch without Wiring Switch Decoration Tool

Parameter 1 Product model KG2201F 10A2 Working voltage AC90 250V3 Quiescent current 8mA4 Working frequency 433MHz5 Load power 2200W6 Receiving sensitivity 105dbm7 Frequency deviation ±0 2MHz8 Coding method learning type9 Working mode self locking interlock delay10 Modulation method ASK11 Remote control distance 100M open place without interference 12 PCBA size 63mm 43mm 20mm13 Shell size 89MM 51MM 26M14 Working temperature 10℃ 80℃Package included 6PCS Receiver1PCS Remote controlPairing method Turn on the power the red and green indicator lights will light up at the same time the two lights will turn yellow together press the manual button once the green light will go out and the red light will stay on 1 Press the pairing button 8 times continuously the red light flashes 3 times and then goes out the code clearing is successful 2 Press the pairing button twice continuously the red light is on and flashing slowly indicating that you are waiting for pairing press the remote control button the red light flashes 3 times and goes out and the self locking mode is set successfully 3 Press the pairing button 3 times in succession the red light is on and flashing slowly indicating that you are waiting for pairing press the remote control button A the red light flashes 3 times and goes out release your finger and then press the remote control B button the red light is fast Flashes 3 times and goes out release your finger the in
