KST Servo Programming Tool Card for KST Servo V6.0 And V8.0

Specification 1 Power input use XT60PW socket to connect with XT60 plug on the adapter end 1 1 Tool 1 power input range is DC5 0V 28V 1 2 The power input needs to input different voltages according to the working voltage range of different models of KST servos Do not input high voltage at will In order not to cause Tool 1 and the servo to burn out the input voltage here will be directly output to the servo terminal pay special attention For example X20 12 M 835 1 working voltage range is 9 13V then the input voltage range of DC terminal is DC9V 13V 2 Output interface Connect to KST steering gear There are two groups of interfaces in two rows each of which can only be used in one group and the other one is spare When connecting the servo press the signal mark S to connect please identify the direction before connecting usually orange or white corresponds to the S end DC DC power supply negative DC DC voltage positive S Signal PWM signal3 Power on and setting operation steps3 1 Connect the power supply After power on Tool 1 will enter the self test After the self test is successfully completed the buzzer will sound 2 times and the orange power light of P LED will always blink At this time it enters the state of waiting to connect the servo 3 2 Confirm the working voltage range of the steering gear and connect the steering gear to the S port after OK After connecting the servo the program will automatically recognize a
