KING PIGEON® M150T 8DI+4AI+4DO+1RS485+1Rj45 Modbus Wet Contact TCP Server and Client Module Ethernet Remote IO Module IO

Note Please refer to the title for the actual supported functions This M150T version Support 8DI 4AI 4DO 1RS485 1Rj45 Modbus Wet ContactDocuments Manual Click here to openTool Click here to openThe difference between switch input dry contact and wet contact Dry contact External disconnection the corresponding internal data is 0External closure the corresponding internal data is 1Wet contact Logic 0 0 3VDCLogic 1 10 30VDCDescription The M150T Ethernet Remote I O Module is an industrial class isolated designed high reliability high stability and high precision data acquisition module embedded 32 Bit High Performance Microprocessor MCU Integrated 1 Industrial 10 100M adaptive Ethernet module inside It provides multi I O supports standard Modbus TCP can be intergraded into SCADA OPC server and other automation systems It is design for working in the harsh industrial application environment widely used in a variety of industrial automation security monitoring system automatically measurement and control system The Ethernet Remote I O module provides a RS485 interface through the RS485 bus it can cascade Modbus RTU I O devices or Modbus RTU meters e g a variety of digital input or digital outputs analog inputs or outputs thermal resistance IO module combination save costs At the same time the Ethernet Remote I O module has register mapping function the cascade Modbus RTU I O data are automatically collected to the mapping memory area the Modbus TCP
