KEYES Open Source LGT8F328P Control Module Development Board

Features compatible boards usually use Microphip microcontrollers but just like GD32 cloning STM32 some companies are making MCU clones usually with some improvements LogicGreen s LGT8F328P microcontrollers mostly are designed with ATMega328P microcontrollers and add functions such as DAC output PWM specific functions computational accelerator DSC The clock speed of the MCU is also double 32 MHz Keyes LGT8F328P control board is a development board based on LGT8F328P chip It is compatible not only with OCROBOT 0 1 2 IDE but also withIDE Before using we need to install driver for the USB serial port chip of the control board The USB serial port chip of the control board is HT42B534 1 The control board uploads code and communicates via the Micro USB interface for which we provide a Micro USB cable in particular At the same time in order to facilitate customers to connect the sensor module with the control board some of the main signal terminals of our special board control board are extended to the 3IN connection mode GNC VCC signal terminal in which the voltage of VCC terminal is 5V Specification Main control chip LGT8F328PUSB serial port chip HT42B534 1Input Voltage DC 5V Micro USB Power Supply Output Current Total 80mACommon port drive current 12 mADigital ports 27 RX0 D0 TX1 D1 D2 D13 A0 D14 A1 D15 A2 D16 A3 D17 A4 D18 A5 D19 E1 D20 E3 D21 SWC D22 SWD D23 E4 D24 E5 D25 AREF D26 Analog port 8 A0 A5 A6 PE1
