KELLYS Soot 30 Bike - Green

FRAME:
KELLYS Soot the best road bike for Off-road optimised and comfortable frame with thru axlesallow to ride SOOT almost everywhere - from paved roads to off-road trails. Carbon fork ensures lighntess and absorbs vibration for even better comfort.
BRAKES:
TRP Spyre disc brakes with a dual sided pads actuation ensures great stopping power and modulation so deserved by all gravel bikers.
DRIVETRAIN:
Shimano Claris drivetrain with entry level pricing ensures great performance and durability for both training and racing.
WHEELS:
17 mm wide rims and 35C Schwalbe Rapid Rob tyres combo provides low rolling resistance with lots of comfort and grip.
SPECIFICATIONS
FRAME Kellys Gravel Concept - Aluminium alloy Disc, flat mount, tapered HT, internal routing, 12x142mm thru axle
FRAME SIZE S (490mm) / M (515mm) / L (540mm)
FORK KELLYS Carbon Disc (1.5 tapered steerer / 12x100mm thru axle)
HEAD PARTS FSA 1.5 semi-integrated
B.B.PARTS SHIMANO BB-RS500
CRANKSET SHIMANO Claris R2000 compact (50x34) - length 170mm (S), 175mm (M - L)
SHIFTERS SHIMANO Claris ST-R2000 Dual Control
F/DERAILLEUR SHIMANO Claris R2000
R/DERAILLEUR SHIMANO Claris R2000 (direct mount)
SPEED 16
CASSETTE SPROCKET SHIMANO CS-HG50-8 (11-32)
CHAIN KMC Z7 (108 links)
BRAKES TEKRO Spyre Mechanical Disc (flat mount)
BRAKE ROTORS 160mm front / 160mm rear
BRAKE LEVERS SHIMANO Claris ST-2000 Dual Control
BRAKE INNER WIRE JAGWIRE stainless
HUBS NOVATEC Disc (32 holes)
THRU AXLE Mr. Control 12x100mm front / Novatec 12x142mm rear
RIMS KELLYS Grind Disc 622x17 (32 holes / 1 eyelets)
SPOKES stainless steel black
TIRES SCHWALBE RapidRob 35-622 (700x35C)
STEM KLS Active Road - diam 28.6mm / bar bore 31.8mm / 6° / length 90mm (S), 100mm (M), 110mm (L)
HANDLEBAR GravelBar - diam 31.8mm / width 400m (S), 420mm (M), 440mm (L)
GRIPS KELLYS bar tape
SEAT POST KLS Active Road - diam 30.9mm / length 350mm (M), 400mm (L)
SADDLE KLS SlipStream cr-mo
GEOMETRY
SIZE GUIDE
