KELLYS Phanatic 70 Large - Blue Mountain Bike

FRAME:
All-new aluminium alloy frame with Sport Cross Geometry ensures the true cross experience with comfortable position along with the low weight, durability and neutral both on- and off-road handling.
DRIVETRAIN:
Durable 3x10 Shimano Deore/XT drivetrain is precise ensuring swift shifting and ultra-wide gear range suitable for every terrain.
BRAKES:
Powerful and precise Shimano hydraulic disc brake system promises confident control of the speed and easy stops in emergency situations.
FORK:
Cross-optimised SR Suntour NRX-D with adjustable air spring and Remote Speed Lockout is ready to offer both a high level of comfort and amazing pedalling efficiency when needed.
SPECIFICATIONS
FRAME
KELLYS Crossforce Lite - Sport Cross Geometry, tapered HT, internal routing
FRAME SIZE
430mm (S) / 480mm (M) / 530mm (L)
FORK
SR SUNTOUR NCX-D RL Air, 75mm, air / Remote Speed Lockout
HEAD PARTS
semi-integrated
B.B.PARTS
SHIMANO BB52
CRANKSET
SHIMANO T551 Hollowtech II (48x36x26) - length 170mm (S), 175mm (M - L)
SHIFTERS
SHIMANO Deore SL-M6000 Rapidfire Plus
F/DERAILLEUR
SHIMANO Deore T6000 (31.8mm)
R/DERAILLEUR
SHIMANO XT M781 (direct mount)
SPEED
30
CASSETTE SPROCKET
SHIMANO CS-HG50-10 (11-36)
CHAIN
KMC X10EL (114 links)
BRAKES
SHIMANO MT500 Hydraulic Disc
BRAKE ROTORS
SHIMANO 160mm front / 160mm rear
BRAKE LEVERS
SHIMANO BL-MT500
HUBS
SHIMANO M475 Disc (32 holes)
RIMS
KLS Draft Disc 622x19 (32 holes / eyelets)
SPOKES
stainless steel black
TIRES
SCHWALBE XC Comp - Puncture Protection 40-622 (700x38C) ReflectiveLine
STEM
KLS Advanced - diam 28.6mm / bar bore 31.8mm / 7° / length 100mm (S), 110mm (M), 120mm (L)
HANDLEBAR
KLS Advanced FlatBar - diam 31.8mm / width 640mm (S, M), 660mm (L)
GRIPS
KLS Token 2Density
SEAT POST
KLS Advanced - diam 27.2mm / length 350mm
SADDLE
SELLE ROYAL Lookin Sport Visual Royalgel
PEDALS
VP NonSlip - alloy
GEOMETRY
SIZE GUIDE
