KELLYS Phanatic 10 Bike Medium - Red

The Men’s Cross Bike KELLYS PHANATIC 10 28” – 2020 is a modern cross bike with the high-quality, lightweight KELLYS Crossforce Lite aluminum frame and top-quality components. The SR SUNTOUR NEX-HLO suspension front fork with 63mm travel, 27 speeds and hydraulic disc brakes provide excellent riding characteristics. The Cross Bike KELLYS PHANATIC 10 also features a lever gear shifter and high-quality Shimano and Kellys components. If you are planning on riding not only in challenging terrain but also on asphalt roads, this bike is the perfect choice.
FRAME:
The new aluminum gold frame with Sport Cross geometryguarantees a real cross experience and comfort . It is light, durable and easy to handle on the road , but also when driving off-road
FORK:
Optimized for cross rides . The SR Suntour NEX with Speed ​​Lockout offers a high level of comfort and great pedaling efficiency
TRANSFER:
The Shimano transmission system has low rolling resistance, is robust and ensures smooth shifting and a wide range of options for any terrain
COCKPIT:
Designed for cross-country riding, the adjustable stem together and the handlebars with soft grips, promise comfort on short and long trips .
SPECIFICATIONS
FRAME KELLYS Crossforce Lite - tapered HT, internal routing, integrated kickstand mount
FRAME SIZE S / M / L
FORK SR SUNTOUR NEX HLO, 63mm, coil spring
MAIN COMPOSITION semi-integrated
MIDDLE COMPOSITION cartridge (113mm)
HANDLES SR SUNTOUR XCM (48x36x26T) - length 170mm (S), 175mm (M - L)
SORTING SHIMANO ST-EF505-9 EZ-fire Plus
DERAILLEUR SHIMANO TY710 (31.8mm)
CONVERTER SHIMANO Acera M3000 (direct mount)
NUMBER OF TRANSFERS 27
CASSETTE PINIONS SHIMANO CS-HG200-9 (11-34T)
CHAIN KMC X9 (114 links)
BRAKES SHIMANO ST-EF505 / MT200 Hydraulic Disc
BRAKE DISCS 160mm front / 160mm rear
BRAKE LEVERS SHIMANO ST-EF505 EZ-fire Plus
BULLETS SHIMANO TX505 Disc Center Lock (32 holes)
RIMS KLS Draft Disc 622x21 (32 holes / eyelets)
WHEEL STRING stainless steel black
TIRES INNOVA 44-622 (700x42C)
STEM KLS CRX 70 adjustable - diam 28.6mm / bar bore 31.8mm / length 95mm (S - L)
HANDLEBARS KLS CRX 70 RiseBar - diam 31.8mm / rise 25mm / width 640mm (S - M), 660mm (L)
HANDLES KLS Token 2Density
SEATPOST KLS Active - diameter 27.2mm / length 350mm
SEAT SELLE ROYAL Vivo
PEDALS NonSlip - alloy
GEOMETRY
SIZE GUIDE
