KELLYS Phanatic 10 Bike Medium - Dark Ocean

FRAME
Brand new aluminum frame with Sport Cross Geometry, which ensures a real cross experience in a comfortable position, as well as low weight, durability and unparalleled road holding on both asphalt and off-road.
FORK
Cross-optimized with SR Suntour NEX Speed ​​Lockout provides a high level of comfort and excellent drive efficiency when needed.
DRIVE
Shimano drive with low maintenance, strong design, fast shifting and a wide range of gears suitable for all terrains.
CONTROL
Cross-profile with adjustable stucco, handlebar and soft grip for comfort on both short and long journeys.
SPECIFICATIONS
FRAME
KELLYS Crossforce Lite - tapered HT, internal routing, integrated kickstand mount
FRAME SIZE
M / L
FORK
SR SUNTOUR NEX HLO, 63mm, coil spring
HEAD PARTS
semi-integrated
B.B.PARTS
cartridge (113mm)
CRANKSET
SR SUNTOUR XCM (48x36x26T) - length 175mm
SHIFTERS
SHIMANO ST-EF505-9 EZ-fire Plus
F/DERAILLEUR
SHIMANO TY710 (31.8mm)
R/DERAILLEUR
SHIMANO Acera M3000 (direct mount)
SPEED
27
CASSETTE SPROCKET
SHIMANO CS-HG200-9 (11-34T)
CHAIN
KMC X9 (114 links)
BRAKES
SHIMANO MT200 Hydraulic Disc
BRAKE ROTORS
160mm front / 160mm rear
BRAKE LEVERS
SHIMANO ST-EF505-9 EZ-fire Plus
HUBS
SHIMANO TX505 Disc Center Lock (32 holes)
RIMS
KLS Draft Disc 622x21 (32 holes / eyelets)
SPOKES
stainless steel black
TIRES
INNOVA 44-622 (700x42C)
STEM
KLS CRX 70 adjustable - diam 28.6mm / bar bore 31.8mm / length 95mm
HANDLEBAR
KLS CRX 70 RiseBar - diam 31.8mm / rise 25mm / width 640mm (M), 660mm (L)
GRIPS
KLS Token 2Density
SEAT POST
KLS Active - diam 27.2mm / length 350mm
SADDLE
SELLE ROYAL Vivo
PEDALS
alloy
GEOMETRY
SIZE GUIDE
