KELLYS Arc 50 Bike - Red

FRAME:
The endurance-optimisedgeometry of lightweight aluminium alloy frame along with the carbon fork ensures top-notch handling and high-speed stability with long-distance comfort.
DRIVETRAIN:
Race-proven 2x11 Shimano 105drivetrain is precise, lightweight and durable providing wide gearing range.
BRAKES:
Powerful Shimano disc brakes with 160 mm rotors ensure top-notch performance and low-maintenance.
FORK:
Aero-optimized carbon monocoque fork with carbon steerer saves weight ensuring precise handling and stiffness.
SPECIFICATIONS
FRAME
KELLYS Endurance Concept - Aluminium alloy Disc, flat mount, tapered HT, internal routing
FRAME SIZE
S / M / L
FORK
KELLYS Carbon Disc - 1.5 tapered steerer, post mount disc brake
HEAD PARTS
FSA 1.5 semi-integrated
B.B.PARTS
SHIMANO BB-RS500
CRANKSET
SHIMANO RS510 compact (50x34T) - length 172.5mm (S - M), 175mm (L)
SHIFTERS
SHIMANO 105 ST-R7000 Dual Control
F/DERAILLEUR
SHIMANO 105 R7000 (braze on)
R/DERAILLEUR
SHIMANO 105 R7000 (direct mount)
SPEED
22
CASSETTE SPROCKET
SHIMANO CS-R7000-11 (11-32T)
CHAIN
KMC X11 EL (108 links)
BRAKES
TEKTRO Spyre Mechanical Disc
BRAKE ROTORS
160mm front / 160mm rear
BRAKE LEVERS
SHIMANO 105 ST-R7000 Dual Control
HUBS
NOVATEC Disc (28 holes)
RIMS
KELLYS Spark 622x15 (32 holes / eyelets)
SPOKES
stainless steel black
TIRES
SCHWALBE Lugano K-Guard 25-622 (700x25C)
STEM
KLS Active Road - diam 28.6mm / bar bore 31.8mm / 6° / length 90mm (S), 100mm (M), 110mm (L)
HANDLEBAR
KLS Active Road - diam 31.8mm / width 400m (S), 420mm (M), 440mm (L)
GRIPS
KLS bar tape
SEAT POST
KLS Active - diam 30.9mm / length 350mm (S - M), 400mm (L)
SADDLE
KLS SlipStream cr-mo rails
GEOMETRY
SIZE GUIDE
