Jumper SF610 6CH Full Range S-FHSS Receiver SBUS PWM Output for T8SG Futaba T14SG Radio Transmitter

Jumper SF610 6CH Full Range S-FHSS Receiver SBUS PWM Output for T8SG Futaba T14SG Radio Transmitter Introduction: The Jumper SF series of receivers offer a high quality yet affordable S-FHSS solution for modelers. The SF Series can be used as a standard PWM receiver or in S.Bus mode for drones or fixed wing craft, robotics, boat or anything that uses an advance control system requiring S.Bus input. The SF series are a full range receiver featuring dual antennas for diversity reception. When reliable quality receivers can be had at this price why risk any alternative. Specification: Brand Name: Jumper Item Name: 2.4G 6CH Full Range Compaitble S-FHSS Receiver Model: SF610 Working Voltage: 3.6~7.5V Working Vurrent: 45~60mA Working Temperature: 0-70 C Delay: Normal Mode 13.6mS Special Mode 20.4mS Effective Distance: >1.8km Weight: 6.8g SBUS: Yes Full Range: Yes Dual Diversity Antenna: Yes Application: Compatble with Jumper T8SG/T8SG v2/T8SG v2 Plus/T8SG Lite/T12 Futaba T4YF/T6J/T6K/ T8J/T10J/T14SG/T18MZ/T18SZ Ground System 3PL/ T3PRKA/ 4PLS/ T4PX/ T4GRS. Bind/Pair procedure: 1. Turn on your transmitter and select S-fhss if it is necessary, 2. Press and hold the bind button on the receiver and power on the receiver, 3. When the LED turns on solid green, bind finish. 4. Then you can connect servos to each channel and check for correct function from stick and switch movement on your radio. PWM output mode and Sbus output mode Setting PWM Mode (normal mode): All channels will output PWM. All SF series receivers are set to PWM as default. S.bus Mode (Special mode): The last channel of the receiver will output S.bus. All other channels will output PWM. How to change modes? - Turn off your transmitter, the LED will be red, - Hold and press the bind button for 6 to 0 seconds, - Then release the button and the red led will flash fast, - Press the bind button quickly once to confirm while the red led is still flashing. Notice: The SF series receivers have a failsafe mode similar to original Futaba Receivers. Before flight, we strongly recommend that fail safe modes are correctly setup on your receiver. Package Included: 1x Jumper SF610 Receiver
