Juki MO-6804S Single Needle 3-Thread Direct Drive Overlock Industrial Machine

Juki MO-6804S-0E4-30H-DD10K 1 Needle, 3 Thread Direct Drive Over Lock Sewing Machine is supplied as complete set (machine, direct drive motor pre-installed and table stand from China). If installation is required, please contact the vendor for service charges. The machine is widely applicable to the sewing of light- to heavy-weight materials. Since the machine is provided with a needle thread take-up mechanism and a looper thread take-up lever, it ensures high-quality, well-tensed and soft seams with a beautiful texture which flexibly correspond to the elasticity of the materials even when run at speeds as high as 7,000 sti/min. The optimally-balanced design of the machine reduces both operating noise and vibration, contributing to more comfortable sewing work. Machine Specifications • Stitch Type: 1 Needle Overlock • Stitch Style in USA: 504 • Max Sewing Speed: 7,000 Stitches per Minute • Stitch Length: 0.6 ~ 3.8 (4.5) mm • Overedging Width (mm): 1.5, 4.0 • Differential Feed Ratio: For gathering 1:2 (Max. 1:4), For stretching 1:0.7 (Max. 1:0.6) • Needle Bar Stroke: 24.5mm(60H:27.0mm) • Inclination Angle of the Needle: 20° • Needle Bar Bushing: Lower bushing method • Needle: DC×27 (excluding some subclass model) • Max. Lift of the Presser Foot: 7mm (excluding some subclass model) • Max. Presser Foot Pressure: 63.7N (6.5kgf) • Stitch Adjusting Method: By push-button • Differential-Feed Adjusting Method: By lever (with micro-adjustment) • Weight of the Machine Head: 27kg • Lubrication: Automatic • Lubricating Oil: JUKI Machine Oil 18 (equivalent to ISO VG18) • Needle Cooler: Provided as standard • Needle Thread Heat Remover: Provided as standard • Micro-Lifter: Option
