Jual coating thickness gauge without battery RESETO F6 Limited

RESETO coating thickness gauge can measure the coating thickness of all non-magnetic coatings on steel (such as paint, powdercoating, plastic, zinc, copper, tin and nickel).The measurement is fast, accurate and non-destructive. For more than 30 years, RESETO gauge has become a widely used instrument for automatic determination of coating thickness.Our RESETO instruments are of the highest level in technology and accuracy
All instruments of resto coating thickness gauge conform to DIN, ISO and ASTM standards.
It has the following characteristics in use:
1. Automatic measurement can avoid misoperation
2. Easy to master and accurate measurement
3. No need to calibrate, set and test
4. No battery or other power supply is required
5. Automatic thickness reading
6. One point measurement with non-destructive probe
7. Metal armor is suitable for frequent outdoor operation
8. Resistance to mechanical impact, acid and solvent corrosion
9. The balance device eliminates the influence of gravity and can measure accurately in any direction and in the tube.
TYPE
measuring range
Reading accuracy ±
Min Diameter of measuring area mm
Min Thickness of base mm
Applicable occasions
RESETO G6
0-100μm
1μm or 5％Reading
20mm
0.5
Electroplated coating, paint, enamel, plastic and rubber layer on steel and iron substrate
RESETO F6
0-1000μm
3μm or 5％Reading
30mm
0.5
RESETO S3
0.2-3mm
5％Reading
30mm
1.0
RESETO S5
0.5-5mm
5％Reading
50mm
1.0
RESETO S10
2.5-10mm
5％Reading
50mm
2.0
RESETO NiFe50
0-50μm
2μm or 8％Reading
20mm
0.5
Nickel plating on steel substrate
SKU : 3131/1316614940440313856/55
