JVC JCV ProHD DT-N17F 21.5" Full HD Broadcast Studio LED Monitor, 1920x1080

• SDI Timecode (LTC, VITC1&2) and AFD info display• R/G/B/Mono, False color, Zebra stripes display• Peaking focus assist display mode• H/V delay, freeze frame display mode• Safety area selection: 80%, 85%, 90%, 93%, 95%• Scale marker: 4:3, 13:9, 14:9, 15:9, 1.85:1, 2.35:1• Native scan, over scan and normal scan selection• GPI control via RS485 port connection• 3 User setting data storage• TALLY light with adjustable brightness• 4 User definable function keys• Easy One-key Menu operation• Built-in speakers (2.5W½ 2, 8O)• Anton Bauer plate for field application Supports 3G/HD/SD-SDI and 2K-SDI DT-N21F supports up to 3G-SDI (SMPTE 425M) including Level-A and Level-B, which are capable of transferring 1080p uncompressed digital video data at a max rate of 60fps at 3Gbit/s. 2K-SDI (2048x1080p) is also supported to down sample to full HD display. Full HD LCD panel with LED backlighting The monitor features a 1920½ 1080 pixel full HD resolution LCD panel with LED backlighting, with 178 deg. wide viewing angle (horizontal and vertical), 1000:1 contrast and 16.7M color depth. ITU-709 color space The DT-N21F is compatible with ITU-709 standard color space for HDTV broadcasting. Selectable gamma preset The DT-N21F supports gamma preset selection from: 2.2, 2.4 and 2.6. TSL UMD control and display The DT-N21F monitor supports UMD controlling input via RS485 and RS232 port, compatible with TSL 3.1 and 4.0 UMD protocol. USB firmware upgradable The Monitor offers a USB port on the rear side, for monitor firmware upgrade. Users can download firmware from official website to a USB stick and the upgrade operation is directly on the monitor, without PC or other adaptors. Built-in waveform monitor The DT-N21F supports waveform selection display (Y, Cb, Cr, R, G, B) and also supports single lines waveform display. The waveform pattern position can be selected from one of four corners and center in larger size.And waveform display color can be selected from white, green and false color, with the translucence also selectable. Built-in vector scope and histogram monitor The DT-N21F supports vector scope and R/G/B/Y histogram display. The vector scope colors can be selected from white, green and false color and the position of the patterns can be selected from one of four corners and the translucent is also selectable. 16-ch audio level meters with alert and output selection The monitor can de-embed audio from SDI and HDMI and display 16-ch audio level meters, with audio abnormal alerts info displayed on each audio bar. You can also select any 2 channels audio to output via 3.5mm socket or speakers. The audio meter pattern position can be selected from one of four corners and you can select to display only 2 channels, 8 channels and full 16 channels. Also scale markers, alert info and translucent of the audio meter pattern are selectable.
