JVC DT-N24H 23.8" Full HD Broadcast Studio LED Monitor, 1920x1080

DT-N24H supports 3G-SDI (SMPTE 425M) Level-A & B, 2K-SDI (SMPTE 2048-2) 60p Level-A & B display. • SDI Timecode (LTC, VITC1&2) and AFD info display • R/G/B/Mono, False color, Zebra stripes display • Peaking focus assist display mode • H/V delay, freeze frame display mode • Safety area selection: 80%, 85%, 90%, 93%, 95% • Scale marker: 4:3, 13:9, 14:9, 15:9, 1.85:1, 2.35:1 • Native scan, over scan and normal scan selection • GPI control via RS485 port connection • 3 User setting data storage • TALLY light with adjustable brightness • 4 User definable function keys • Easy One-key Menu operation • Built-in speaker (2.5W, 8) • AntonBauer battery plate for field application (V-mount plate in an option) Full HD LCD panel with LED backlighting The monitor features a 1920x1080 pixel full HD resolution LCD panel with LED backlighting, with 178 deg. wide viewing angle (H & V), 1000:1 contrast and 16.7M color depth. ITU-709 color space The DT-N24H is compatible with ITU-709 standard color space for HDTV broadcasting. Selectable gamma preset The DT-N24H supports gamma preset selection from: 2.2, 2.4 and 2.6. Audio meters display The DT-N24H supports SDI/HDMI embedded audio 2-ch meters display and analog audio 2-ch meters display. TSL UMD control and display The DT-N24H monitor supports UMD controlling input via RS485 and RS232 port, compatible with TSL 3.1 and 4.0 UMD protocol. USB firmware upgradable The Monitor offers a USB port on the rear side, for firmware upgrade. Users can download firmware to a USB disk and the upgrade operation is directly on the monitor, without PC or other adaptors.
