JUNTEK™ JDS6600 DDS Signal Source Dual Channel Arbitrary Wave Function Generator Frequency Count
![JUNTEK™ JDS6600 DDS Signal Source Dual Channel Arbitrary Wave Function Generator Frequency Count](http://imgaz3.staticbg.com/thumb/large/oaupload/banggood/images/00/A1/ce7d0ef4-2bd9-4b64-927e-89d1727b56b4.jpg)
JUNCTEK
sku: 1148682
type: Electronic Components & DIY Kits
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$89.99
Shipping from: China
Description
Description JDS6600 series DDS signal generator can generate sine wave square waves triangle wave pulse wave and arbitrary wave etc The frequency will be up to 40MHz And it has duty cycle correction amplitude modulation function and frequency sweep function etc It can show output signal amplitude and frequency in the same time This series has amplitude frequency characteristics and the appearance is very delicate and beautiful It can be applied in factories schools research institutes and laboratories There are 5 models JDS6600 60M JDS6600 50M JDS6600 40M JDS6600 30M and JDS6600 15M The main difference is the max output frequency of sin wave Manual is here Protocol Click here Frequency Characteristics JDS6600 15MJDS6600 30MJDS6600 40MJDS6600 50MJDS6600 60MSine frequency range0 15MHz0 30MHz0 40MHz0 50MHz0 60MHzSquare frequency range0 15MHz0 15MHz0 15MHz0 15MHz0 15MHzTriangle frequency rangePulse frequency range0 6MHz0 6MHz0 6MHz0 6MHz0 6MHzCMOS TTL digital frequency rangeArbitrary wave frequency rangeSquare rise time≤30nS≤25nS≤20nS≤20nS≤20nSMininum Frequency resolution0 01µHz 0 00000001Hz Frequency accuracy±20ppmFrequency stability±1ppm 3hWaveform CharacteristicsWaveformSine Square Triangle Pulse duty cycle correction Partia Sine CMOS DC level Half wave Full Wave Pos Ladder Neg Ladder Noise Exponential Rise Exponential Fall Tone Sinc Pulse Lorentz Pulse and 60 kinds user defined waveform Waveform length2048 pointsWaveform sampling rateJD
