JJRC JJPRO P130 Battler 5.8G FPV Racing Drone RTF with 800TVL Camera

Video
The JJPRO P130 Battler is built on a 3K full carbon fiber frame which should easily withstand unexpected bumps. The drone uses the NAZE32 SP racing F3 flight controller which is essential to deliver fast-paced flying sessions. The Flycolor 12A ESCs also help in this cause by driving the 1806 2300kV brushless motors at high RPMs. The drone also does FPV over 5.8 GHz from its 1/3 inch CMOS, M8 800TVL camera (720p HD quality) with a 150-degree field of view. A 25mW 40-channel FPV transmitter has been integrated in JJPRO P130 Battler to make the drone ready for FPV right out of the box.
1806 2300KV Motor The high-torque motor has a high-purity copper coil that maximizes the efficiency, generating a strong thrust of 200 to 350 G.
FS-i6 6CH Transmitter The transmitter excels in its anti-interference 2.4GHz transmission frequency and the second-generation auto frequency hopping system. And its LCD screen presents all the data and greatly facilitates the control.
800TVL Camera With 150 degree FOV and 170 degree DFOV, the camera boasts the broader vision and higher resolution that offer you with wonderful racing experience.
5.8G FPV Antenna It covers the RaceBand and enables you to watch the spectacular sight in the real time.
Specifications
General
Brand: JJRC
Model: JJPRO P130 Battler
Type: Racing drone
Motor
Model: X1806-16T
KV: 2300
Max. Thrust: 200-350G
Max. Current: 13A
Lipo(S): 2-3S
Height: 21.5mm
Diameter: 23mm
Propeller: 3 inch (3045)
Weight: 17g
ESC
Brand: Flycolor
Model: Fairy-12A
Continuous Current: 12A
Instantaneous Current(10S): 18A
BEC: 5V/1A
Input Voltage: 2-4S
Weight: 9.5g
Size (without plug): 28 x 15 x 6mm
Typical Applications (for reference): 200-330 Multi-copter
Transmitter
Brand: Flysky
Model: FS-i6
Channels: 6 Channels
Model Type: Glider/Heli/Airplane
RF Range: 2.40-2.48GHz
Bandwidth: 500KHz
Band: 142
RF Power: Less than 20dBm
2.4GHz System: AFHDS 2A and AFHDS
Code Type: GFSK
Sensitivity: 1024
Low Voltage Warning: Less than 4.2V
DSC Port: PS2
Output:PPM
ANT Length: 26mm x 2 (dual antenna)
Weight: 392g
Power: 4 x 6V/1.5 AA batteries (not included)
Display Mode: Transflective STN positive type, 128 x 64 dot matrix VA73 x 39mm,white backlight
Size: 174 x 89 x 190mm
Color: Black
Model Memories: 20
Receiver
Model: FS-iA6
Channel: 6CH
Model Type: Fixed-wing/Glider/Helicopter
RF Receiver Sensitivity: -105dBm
Modulation: GFSK
System Type: AFHDS2A/AFHDS
Channel Resolution: 1024 steps
Bind Port: Yes
Power Port: Yes (VCC)
Power: 4.0-6.5V DC
Flight Controller
Model: NAZE32
Size: 3.6cm x 3.6cm
Weight(wiht line): 11g
Camera
Operating Voltage: 3.6-5.5V
Image Sensor: 1/3 inch CMOS
Resolution: 800TVL Lens
Angle: 150° FOV horizontal angle, 170° DFOV opposite view angle
Current: 100mA
Wireless Channel: 40 CH
Sound Carrier: 6.5 MHz
Signal System: NTSC/PAL(One key switch)
Power Consumption: 380mA/3.7V
Output Impedance: 75 ohm
Operating Signal Intensity: 23-24dBm
Lens Diameter: 2.1mm IR coated FOV150°
Size: 18.5 x 16.5 x 8 mm
Weight & Dimension
Package Weight: 2.5kg
Product Size: 18 x 16 x 7.5 cm
Package Size: 42.5 x 10.5 x 27.5 cm
Package Contents
1 x JJPRP P130 Frame Kit
4 x X1806 2300kv Motor
4 x 12A ESC
8 x Propellers
1 x NAZE32 Flight Controller
1 x Section Board
4 x LED Light
1 x 5.8G Image Transmitter (with CMOS 800TVL Camera)
1 x 11.1V 850mAh Battery
1 x Screwdriver
1 x FS-i6 Transmitter/Receiver
