JDS2900 60MHz Signal Generator Digital Control Dual-channel DDS Function Signal Generator Frequency Meter Arbitrary Wave

Features 1 High Performace Total range frequency resolution is 0 01uHz the minimum amplitude resolution can reach 1mV amplitude range is 2mVpp 20Vpp duty cycle of each channel can be adjusted independently the adjusting resolution is 0 1 2 Pulse Output With pulse trains burst output function allow the unit output 1 1048575 arbitrary pulse trains 3 Sweep Function Linear sweep and logarithmic sweep functions 0 1s 999 9s sweep time forward backward and roundtrip sweep directions 4 Measurement Function Can measure signal frequency cycle positive negative pulse width and duty cycle 1Hz 100MHz frequency range 5 Storage Function Can store 100 groups of parameters set by the user and extract at any time Specifications Sine Frequency Range 0 60MHzSquare Frequency Range 0 25MHzTriangle Frequency Range 0 25MHzPulse Frequency Range 0 6MHzTTL Digital Frequency Range 0 6MHzArbitrary Wave fFrequency Range 0 6MHzPulse Width Adjustment Range 25nS 4000SSquare Rise Time ≤10nSMininum Frequency Resolution 0 01µHz 0 00000001Hz Frequency Accuracy ±20ppmFrequency Stability ±1ppm 3hWaveform Characteristic Waveform Sine wave square wave pulse wave adjustable duty cycle pulse width and cycle time triangle wave partial sine wave CMOS wave DC level adjust bias to set DC magnitudes half wave full wave positive step wave negative step wave noise wave index up index down sonic wave sinc pulse Lorentz pulse and 60 kinds of user defined waveformsWaveform
