JDS2012Q Handheld Single-channel Digital Oscilloscope + Multimeter + Load Test Support Analog Bandwidth Storage Waveform

Specification 2012QFunctionsOscilloscope Multimeter Load testLanguageChinese English Russian Portuguese SpanishOscilloscope parametersNumber of channelsSingle channelMaximum real time sampling rateCH1 200MSa s for single channelBandwidth50M for single channelVertical resolution8 bitVertical gear10nV 5V probe x1 100nV 50V probe x10 1 2 5 stepsImpedance1MΩ 25pFCouplingDC ACDisplay modeY TInput voltage40V probe x1 400V probe x10 Use high voltage probes the maximum voltage is determined by the quality of the probeTime base range12 5ns 5s 100ms 5s is the scan mode scan Storage depth3K per channelTrigger modeAutomatic normal and singleTrigger typeRising edge falling edgeAutomatic detection50Hz 20MHzCursor measurementTime voltage current pressure manual mode Can record contrast waveform2Screenshot functionStand bySelf calibrationStand byNumber of screenshots available7Number of waveforms that can be saved30Multimeter parameters Count value 4000 countDC voltage 0 1000V CAT II area AC voltage 0 750V CAT II area Resistance 0 40 00MΩCapacitance 0 100uF at 100uF the charging tine is more than 30 seconds Diode 0 1 5VPackage included 1 x Probe2 x Broken needle1 x Dedicated test line2 x Little clip1 pair test line1 x Charger1 x USB line1 x U diskDetails pictures
