Induction Counter Meter JDM11-6H Panel Reset Counter For Petroleum Chemical Textile Machinery DC12-24V

Induction Counter Meter JDM11-6H Panel Reset Counter for Petroleum Chemical Textile Machinery DC12-24V Specification: Item Type: Digital Electronic Counter Product Model: BEM-6H-04NK-L-CTCounter Model: JDM11-6H Power Consumption: Less than or equal to 10W Counting Range: 1-999999 Counting Speed: 10 times/s Working Method: Continuous working system Counting Method: Contact count level count and sensor count Operating Temperature: -5 degrees Celsius -45 degrees Celsius Storage Temperature: -20 degrees Celsius -70 degrees Celsius Reset Time: Greater than or equal to 0.5s Power Restart: Greater than or equal to 1s Sensing Distance: Approx. 4mm / 0.2in Detection Object: Metal object Reset Method: Panel reset Counting Error: Less than or equal to 1 Data Retention: Greater than or equal to 10 years Power Cord Length: Approx. 1.5m / 4.9ft Sensor Cable Length: Approx. 1.8m / 5.9ft Application: Widely used in petroleum chemical textile machinery mining national defense agriculture food printing and other industries; but for the control of valuable equipment or the situations where the product is damaged and is endangered please do a secondary protection. Working Principle: The sensing distance is 4mm. When metal object passes through the sensor it starts counting. How to Use: The contact input should be reliable to avoid malfunction caused by contact bounce. Reset Function: Press the panel reset button at any time. The counter returns to the initial state and the reset time is Greater than or equal to 0.5 seconds The maximum speed of the calculator is the maximum speed when the duty ratio is 1: 1 and the pulse width of on or off is greater than 50 milliseconds. In the control system the counter control line is wired separately from other power lines; in a strong current environment and the counting terminal wire is please use a shielded wire. Package List: 1 x Counterwith Cable 1 x Metal Rack 4 x Accessories
