ISDS205X Virtual PC USB Oscilloscope DDS Signal and Logic Analyzer 2CH 20MHz Bandwidth 48MSa/s 8bit ADC FFT Analyzer

Description: ISDS205 dual-channel digital oscilloscope, with "low-cost, high-performance" as the design goals. well-designed bandwidth of 20M, 48M sampling rate, 2 channels, alternating support X-T and XY alternating pattern of two-channel virtual oscilloscope, spectrum analyzer, data recorder. Digital Oscilloscope Channels 2 Impedance 1M 25pF Coupling AC/DC Vertical resolution 8Bit Gain range -6V ~ 6V (probe X1) -60V ~ 60V (probe X10) Vertical accuracy 3% Timebase range 1ns-20s Input Protection Diode, 50Vpk Autoset Yes(10Hz to 20MHz) Trigger Mode Auto, Normal and Signal Trigger Type No, Rising edge, Falling edge, Rising edge or Falling edge Trigger level Yes Trigger Source CH1, CH2 Buffer Size 1MB/CH Bandwidth 20MHz Max sample 48MS/s Vertical mode CH1, CH2, ADD, SUB, MUL Display Mode X, Y-T & X-Y measurements Yes Wave save Osc(Private) Excel and Bmp Spectrum Analyzers Channels 2 Bandwidth 20MHz Algorithm FFT(18 windows) correlation FFT points 8-1048576/CHN FFT measure Harmonic(1-7) SNR, SINAD, ENOB, THD, SFDR Filter processing FIR filter supports arbitrary range of frequency sampling method and Rectangle, bartlett, triangular, cosine, hanning, bartlett_hanning, hamming, blackman, blackman_Harris, tukey, Nuttall, FlatTop, Bohman, Parzen, Lanczos, kaiser, gaussand dolph_chebyshev, window method design. IIR filter support "Butterworth" "Chebyshev I" "Chebyshev II" "Elliptic" type of filter design Note: The oscilloscope factory calibration, if you are not satisfied with the measurements, canmanual calibration, the specific reference oscilloscope instructions. Data Recorder Channel 2 Impedance 1M 25pF Coupling AC/DC Vertical resolution 8Bit Gain range -6V ~ 6V (probe X1) -60V ~ 60V (probe X10) Sample 1 channel : 1K~24M Hz 2 channel : 1K~16M Hz Save File The maximum 4G, recording time associated with the sampling rate Note: The specific speed recorder with computer processing speed, and if use high sampling rate, the situation may break. Logic Analyzer(205C/205X) Channel 16 Sample 8 channel: 250K-24M Hz; 16 channel: 250K-16M Hz Sample points 1M-2GB Saleae Logic Logic Analyzer (205C/205X) Channel 8 Sample 25K-24M Hz Protocol Analyzer Atmel SWI BiSS C SPI I2C CAN UART I2S/PCM DMX-512 JTAG LIN Manchester 1-WIRE UNI/O Simple Parallel MDIO USB1.1 PS/2 Keyboard/Mouse Sample points 1MB-10TB DDS(205B/205X) Wave Sine, Square(Duty circle variable),Triangle,Up Sawtooth,Down Sawtooth Amplitude 9Vp-p(no load) Impedance 20010% Offset 2.5V Frequency range 1Hz - 20MHz(Sine) 1Hz - 2MHz(Others) Frequency resolution 1Hz Frequency steadiness 110-3 Frequency precision 510-3 Triangular wave linearity 98% (1Hz-10kHz) Sine wave distortion 0.8% (1kHz) Square wave rising/falling time 100ns Square wave duty circle 1%-99% SWEEP Sweep range Fs Fe Sweep time range 0.1 - 10 s Amplitude 0.5Vp-p - 10Vp-p Package included: 1 x ISDS205X 5 in 1 Oscilloscope 1 x USB Cable 1 x BNC Clip Probe 1 x Pair Oscilloscope Probe 1 x Set Logical Cable 1 x CD Detail Pictures:
