INTBUYING Hydraulic Hole Punching Tool Metal Plate Copper Hole Puncher Portable Small Punch CH-60A

☞Description: It is split hole puncher. It is used for punching for metal plate. It is popular in electricity industry construction etc. It need to work with a pump. It could punch 0.41 (ф10.5mm) 0.54 (ф13.8mm) 0.67 (ф17mm) 0.81 (ф20.5mm). NOTE: You are bidding a Hydraulic Hole Punching Tool without pump ☞ Parameter: Punching force: 310KN(31T) Depth of throat: 3.74 (95mm) Aperture(4 pairs): 0.41 (ф10.5mm) 0.54 (ф13.8mm) 0.67 (ф17mm) 0.81 (ф20.5mm) Max. Thickness of iron plate: 0.24 (6mm) Max. Thickness of copper bar: 0.39 (10mm) Max. Thickness of angle iron: 3-10# Weight: 39.6LB(18KG) ☞ Feature: 1. Hydraulic Hole Punching Tool CH-60 apply to L and H style flat copper and busbar. 2. End is designed with flat seat smooth and not fall 3. Single oil return punch dies made of high carbon tungsten steel and not easy to wear off. Item Included: Item Included: Y-148027 1*Hydraulic Hole Punching Tool 1*concave pressing plate 4*dies:(one of the four is in the puncher) 0.41 (ф10.5mm) 0.54 (ф13.8mm) 0.67 (ф17mm) 0.81 (ф20.5mm) INTBUYING Hydraulic Hole Punching Tool Metal Plate Copper Hole Puncher Portable Small Punch CH-6A
