Hydraulic Cable Crimper Hydraulic Wire Crimper 16-240mm² For Transportation Communication

Hydraulic Cable Crimper Hydraulic Wire Crimper 16-240mm² for Transportation Communication Specification: Item Type: Hydraulic Cable CrimperMaterial: Cemented carbide Hydraulic Oil: 15# hydraulic oil Wiring Range: Aluminum 16-240mm² Copper material 16-150mm² Maximum Working Pressure: 16T Maximum Working Stroke: Approx. 22mm / 0.9in Hex Pressure: Crimping form Hex Module Configuration: 16/25/35/50/70/95/120/150/185/240m㎡ Product Length: Approx. 410mm / 16.1in Uses: Ideal hydraulic tools for connecting copper and aluminum terminal interfaces of cables and wires with end and connecting pipes as well as tools for industrial and agricultural power users such as communications transportation petrochemicals metallurgy shipbuilding etc. How to use: 1. Install the corresponding die pull the movable hand back and forth and the oil circuit retreats the piston to force the movable die to until the two pressure dies touch slightly. Then loosen the oil return switch not too much to turn on the oil return switch. Due to the elastic force of the oil return spring the oil is returned to the oil storage pipe that is the movable die is reset. For example when the copper sleeve is crimped the copper sleeve Anneal treatment first to ensure the quality of crimping. 2. When crimping the wires just press the upper and lower dies slightly. If the pressure is continued after the upper and lower dies are slightly touched the parts will be damaged. 3. When using crimping it is forbidden to knock the head and die to avoid deformation and damage. 4. Hydraulic clamps and wires should not be used in acid alkali and corrosive gas. 5. The hydraulic tongs must keep enough filtered hydraulic oil. Package List: 1 x Hydraulic 2010 Pairs x Dies 5 x 1 x Storage Box Note: Please note that the new type and old type of this product will be sent randomly and make sure you will not mind before ordering.
