Hybrid Stepper Motor Driver Two Phase CNC Controller 0.2-5A TB6600 DC12-48V Input

Item Type: Input Voltage: DC 12-48V Input Input: 1-5A Current Select Drive Stepper Motor Output Current: 0.2A-5A Temperature Operating Temperature: -10-45℃; Storage Temperature -40℃ -70℃ Humidity: No Condensation No Drop Gas prohibits combustible gas and conductive dust Set the Number of Steps Per Motor Step for the Motor 200(synchronizing) 400 (2 segments) 1600 (8 segments) and 3200 Steps (16 segments). Power Interface: 1. DC + DC-: Connect the drive power DC +: DC Power Supply Level Power Supply Voltage Dc 12 To 48v Maximum Current 5a DC-: DC Power Supply Negative Level. 2. A + A-B + B-: Connecting Two-Phase Hybrid Stepping Motor The connection between the driver and the two-phase hybrid stepping motor and the four-wire system the parallel and series connection of the motor windings and the connection method the high-speed performance is high but the driving current is large (the motor winding current is 1.73 times) when the driving current is equal series connection when the motor winding current Troubleshooting: State Light Indication RUN: The Green Light Works Normally. ERR: Red Light Power Indicator Light Power Indicator Control Signal Definition: PUL +: stepping pulse signal input side or positive pulse signal input positive terminal PUL-: Negative input of negative input pulse signal or positive pulse signal DIR +: input the positive direction step direction signal or input positive terminal negative pulse signal DIR-: Negative terminal for step direction signal input or reverse pulse signal input in negative direction EN +: Offline can reset the signal input EN-: Offline resettable signal input negative The two-phase hybrid stepping motor has a dynamic voltage of 12 to 48 V a current of less than 5 A and an outer diameter of 35 to 86 mm. The driver adopts the current loop subdivision control of the driver the motor torsion ripple is small the low speed operation is very stable and there is almost no vibration and noise. High-speed torsion is much higher than other two-phase drives high positioning accuracy Widely used in engraving machines CNC machine tools packaging machinery etc. Average current control two-phase sinusoidal current drive output and opto-isolated signal input/output 6、The product has overvoltage undervoltage overcurrent and short circuit protection 7、The offline enable signal is valid the drive fault is reset to disable any pulses and the motor maintains torsion after the drive output power component is turned off. 8、The PC control signal can be either high or active low. Control signal when active high 9、The negative terminals together act as an active low signal and the positive ends of all control signals are used together as a common signal. 10、The half-flow function is a 200ms step pulse and the driver output current is automatically reduced to 50% of the rated output current to prevent motor heating. 11、There must be 20mm space around and it should not be placed adjacent to other heating equipment to avoid dust oil mist corrosive gas excessive humidity and strong vibration.1 x TB6600 Stepper Motor Driver
