Holybro Kakute F4 AIO V2 Flight Controller PDB OSD+Atlatl HV V2 5.8G 40CH FPV Transmitter for RC Drone

Holybro Kakute F4 AIO V2 Flight Controller PDB OSD Holybro Atlatl HV V2 5 8G 40CH FPV TransmitterHolybro Kakute F4 AIO V2 user munual Brand name Holybro Item name F4 AIO V2 Flight ControllerMCU STM32F405RGT6 32 bit processorIMU ICM20689 SPI Barometer BMP280USB VCP Driver all UARTs usable simultaneously USB does not take up a UART 5 hardware UARTS UART1 3 4 5 6 Supports serial receivers SBUS iBus Spektrum Crossfire only PPM and PWM receivers are not supported 128 Mbit Dataflash chip for Blackbox loggingDimensions 35x43x7mm includes USB in height Mounting Holes Standard 30 5mm square to center of holes Weight 7g Features Additional UART UART 4 added to support serial camera communication such as to RunCam Split Please note this is NOT the same as Betaflight Camera Control feature which controls the menu of FPV cameras like Swift Monster etc Additional UART UART 5 added to support ESC telemetry such as from BLHeli 32 and KISS Through hole solder pads instead of flat pads for more secure soldering especially for beginners Barometer sensor on board allows altitude hold mode I2C pad available for certain external sensors Supports Betaflight and Cleanflight Betaflight OSD Change PIDs adjust common configuration parameters and change video transmitter channel and power level all using your transmitter sticks and goggles Soft mounting built in The IMU gyro chip on this board is mounted on vibration isolating foam This means tha
