Holybro H-RTK F9P Helical GPS Module Base Station for Pixhawk Flight Controller RC Drone FPV Racing

Specification Brand HolybroItem Name H RTK F9P GPS Module GNSSGPS L1C A 1575 42MHz GPS L2C 1227 6OMHz GLONASS L1OF 1602MHz GLONASS L2OF 1246MHz BeiDou B1 1561 098MHz BeiDou B2 1207 140MHz Galileo E1 B C 1575 42MHz Galileo E5b 1207 14OMHz Antenna Peak Gain MAX 2dBiLNA Gain Typical 33±2dBTime to First Fix Cold start ≤25s Hot start≤1s RTK Surveyln Time ≤5 minute 2 0mCEP Data and Update RateRAW 20Hz Max RTK 8Hz Max Moving Base RTK 5Hz Max Port Port 1 GH1 2510 pin Port 2 USB Type C Antenna Connection Type Board SMA female Antenna SMA male Baud Rate 115200 5Hz default can be set Working Voltage 4 75V 5 25V Dimensions Board 34 8 36 3 11 9mm Antenna Diameter 27 5mm Antenna height 59mm Weight 49gDeacription This model uses a helical antenna which has better performance than the lite version This model can be used both on rover aircraft or as base station The aluminum alloy shell design also has a integrated safety switch and a tri colored LED indicator and it is compatible with the open source Pixhawk series flight controller Package Included 1 x H RTK F9P GPS Module1 x High Precision GNSS Antenna CH7604A 1 x Fixed Carbon Fiber GPS mount 29mm 1 x GH 10P cable 150mm 1 x GH 10P cable 400mm 1 x USB type c cable
