Hilitand RF Power RF Signal Power 5-6000MHz Gain 20dB Broadband RF VHF UHF Signal Power Module

Features: This is a 5--6000MHz RF signal power with 20dB gain. It has big dynamic range and wide operating frequency range. The power supply voltage is 5VDC and working current is 85mA. Maximum output power is +21dBm(100mW)@1dB compression point. It is suitable for all types of fixed gain amplification of RF signal. Specifications: Operating Frequency: 5--6000MHz Gain: 20dB maximum. Output Power: +21dBm(100mW)@1dB compression point Working Current: 85mA (5V) Power Supply Voltage: 5VDC System Impedance: 50ohm Size: 34*25mm/1.33*0.98in Note: In use should follow the relevant principles of RF and microwave circuit layout. Package Includes: 1 x RF Power
