Hikvision DS-2CD2742FWD-IS 4MP WDR Vari-focal Dome Camera

The DS-2CD2742FWD-IS from Hikvision is a 4MP IR Vandal-resistant Dome Camera. Its Varifocal lens leaves no angle uncovered. Encased in an IP66 casing, this camera is protected against the elements making it ideal for both internal and external installations.
Features
1/3” Progressive Scan CMOS
Up to 4 megapixel resolution
120dB WDR
3D DNR
Up to 30 meters IR range
Support MicroSD up to 128GB (not included)
Audio/alarm I/O
Mobile Monitoring via cloud P2P or iVMS-4500
12V DC±25% & PoE(802.3af Class3)
Support H.264+
IP67 and IK10 rated for outdoor use
Specifications
Camera
Image Sensor 1/3" Progressive Scan CMOS
Min. Illumination 0.01lux @(F1.2, AGC ON), 0.014lux @(F1.4, AGC ON), 0 lux with IR
Shutter time 1/3 s ~ 1/100,000 s
Slow shutter Support
Lens 2.8-12mm @ F1.4, Angle of view: 112-33.8 degree
Lens Mount 14
Day& Night IR cut filter with auto switch)
Wide Dynamic Range 120 db
Digital Noise Reduction 3D DNR
Compression Standard
Video Compression H.264/MJPEG/H.264+
H.264 code profile Main Profile
Video bit rate 32Kbps~16Mbps
Audio Compression G.711/G.722.1/G.726/MP2L2
Audio bit rate 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2)
Max. Image Resolution 2688 x 1520
Frame Rate 50Hz: 20fps(2688 x 1520), 25fps(1920 × 1080, 1280 × 720)60Hz: 20fps(2688 x 1520), 30fps(1920 × 1080, 1280 × 720)
Image Enhancement BLC/3D DNR/ROI
Image Settings Rotate mode, Saturation, Brightness, Contrast, Sharpness
Day/Night Switch Auto/Schedule/Triggered by Alarm In
Network
Network Storage Built-in Micro SD/SDHC/SDXC slot, up to 128G, NAS(NFS, SMB/CIFS)
Alarm Trigger Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception
Protocols TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
Security One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark,IP addressfiltering
System Compatibility ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI
Interface
Communication Interface 1 RJ45 10M/100M Ethernet interface
General
Operating Conditions -30 °C ~ 60 °C (22 °F ~ 140 °F) Humidity 90% or less (non-condensing)
Power Supply 12V DC ± 10%, PoE (802.3af)
Power Consumption Max. 5.55 W
Weaterproof IP67
Impact Protectio IK10
IR Range Up to 30m
Dimensions ø140 x 99 mm (ø5.51” x 13.94”)
Weight 1000g (12.20 lbs)
