High Precise Thickness Gauge LCD Digital Automobile Film Thickness Meter Car Paint Coating Thickness Tester with Multi-point and Zeroing Calibration Function

Features:
High Sensitivity Probe: Equipped with a high-sensitivity probe to automatically recognize the substrate, only need to be placed on the measured surface, can automatically calculate the thickness of the coating.
Digital LCD Display: LCD display with blue backlight, the large screen will synchronously display the real-time value, maximum value, and minimum value.
Working Principle: The instrument uses two principles of electromagnetic induction and vortex induction, which can measure the coating thickness non-destructively.
Measurement Modes: Two measurement modes to meet different application requirements. For a single measurement, only one measurement data is updated. For continuous measurement, the data is updated continuously.
Fe Iron Base Mode: When the probe and the magnetic substrate with cladding are in close contact, the probe and the magnetic substrate form a closed magnetic circuit, the thickness of the cladding and the magnetic circuit form correspondence, and the purpose of measuring the thickness of this cladding is achieved through the change of the checking resistance.
NFe Non-ferrous Mode: When the probe and the non-magnetic substrate with cladding are in close contact, the probe and the magnetic substrate generate vortices, the feedback effect of the vortex on the probe and the thickness of the cladding forms a corresponding relationship, and the purpose of measuring the thickness of the cladding is achieved by checking the amount of this feedback.
Measurable Objects: Used to measure the thickness of plating or coating on metal surfaces. Specifically, it can measure the thickness of the non-magnetic coating layer on the surface of magnetic materials such as steel/iron, and also the thickness of the coating on the surface of non-magnetic materials such as copper/aluminum. Maximum 1500um coating thickness test, minimum 0.1um resolution.
Multi-functional Design: It supports auto-calibration, beeping reminder, data storage, and automatic shutdown functions.
Rechargeable Battery: Built-in 3.7V 400mA lithium battery, USB direct charging, with long endurance and long service lifespan.
Wide Applications: It is widely used in automotive ink inspection, electroplating layer, surface process, pipeline anti-corrosion layer, surface mechanical equipment anti-corrosion, chemical equipment, quality control and other fields.
