High Frequency Signal Isolator Transmitter 4-20mA PLC Input Signal Conditioner 24VDC
sku: 4000064585960
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$22.00
Shipping from: China
Technical Details
| Accuracy: | 0.1% |
| Accuracy Class: | 0.1% |
| Brand Name: | NoEnName_Null |
| Channels: | 1 in 1out , 1 in 2out, 1 In 4 out, 2 in 2 out |
| characteristics: | Active or passive output switchable |
| Dimension: | 12.7*110*118.9mm;17.7*110*118.9mm |
| Dimensions: | 12.7x110x118.9mm/17.7x110x118.9mm |
| Display Type: | Analog and Digital |
| DIY Supplies: | Electrical |
| Full-load consumption: | 2W |
| Installation: | 35mm DIN rail |
| Insulation intensity: | 3kv/50HZ, one min |
| Iutput Signal: | 4-20mA, 1-5V,0-10V,etc |
| Linearity: | 0.1% |
| Load Capacity: | <=800Ω(output current signal); <=10KΩ(output voltage signal) |
| Model Number: | HDTD |
| Operating Temperature: | -20°C-60°c |
| Output Signal: | 4-20mA, 1-5V,0-10V, etc |
| Power Supply: | DC18-32V |
| Product name: | Signal Isolator/Signal Converter |
| Response time: | 10ms |
| Supply Voltage: | DC18-32V |
| Temperature drift: | 40ppm/Deg.C |
| Warranty: | 5years |
| Weight: | 0.15Kg |
