Hantek DSO3102 Automotive Diagnostic USB Oscilloscope

Features
256M memory depth;.
2/4 channel and EXT trigger.
60-250MHz bandwidth.
1GSa/s real-time sampling rate.
8--36V Wide range of input voltage,suitable for vehicle power test.
More than 20 kinds of automatic measurement function, PASS/FAIL Check function, is suitable for engineering application.
Excellent industrial design, similar interface with bench oscilloscope, easy to use.
Software support: Windows NT, Windows 2000, Windows XP, VISTA, Win7, Win8.
Supply DEMO code(VC, VB, LABIEW) and technical support.
Specifications
Vertical
Channels
2
Bandwidth
60MHz
Rise Time
5.8ns
Input Impedance
Resistance: 1MΩ; Capacitance: 25 pF
Input Sensitivity
10mV/div to 5V/div
Input Coupling
AC/DC/GND
Vertical Resolution
8 bits
Memory Depth
10K-256M/CH
Maximum Input
400V (DC+AC Peak)
Horizontal
Real-Time Sampling Rate
1GSa/s
Time Base Range
5ns/div to 1000s/div(1-2-5 sequences)
Time Base Precision±50ppm
Trigger
Source
CH1, CH2, EXT CH1, CH2,CH3, CH4, EXT
Mode
Edge, Pulse,Video, Alternative
Auto Measurement
Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase, Vavg, Vrms, Vcrms, Preshoot, Overshoot, Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle
Cursors Measurement
Horizontal ,Vertical, Track, Auto Measure Modes
Waveform Signal Process
+,- , x,÷, FFT, Invert
Voltage Range
10mV to 5V/div @ x 1 probe100mV to 50V/div @ x 10 probe1V to 500V/div @ x 100 probe10V to 5000V/div @ x 1000 probe100V to 50000V/div @ x 10000 probe200mV to 100V/div @ 20:1
Current Range
CC65(20A),CC65(60A),CC650,CC1100
FFT
Rectangular,Hanning,Hamming,Blackman Window
Math
Adition,subtraction,multiplication,division
INTERFACE
USB 2.0
POWER SOURCE
8--36V Wide range of input voltage,suitable
Package Size
40 x 30 x 15 cm
Package Weight
4.0kg
