Hantek 1008A 8CH USB Oscilloscope Programmable Generator Vehicle Testing 2.4MSa/s

Features
Highly efficient and cost-effective oscilloscope for vehicle testing.
8 channels oscilloscope, 2.4MSa/s real time sampling rate.
12 bits vertical resolution, spectrum analysis function.
8 channels programmable generator which can analog signals of crankshaft, camshaft etc.
USB 2.0 interface plug and play, and no need extra power supply.
10mV/div to 5V/div, input sensitivity is adjustable.
More than 20 types of automatic testing function, a similar interface with benchtop oscilloscope, easy to use.
Software support: Windows NT, Window 2000, Windows XP, VISTA, Windows 7, Windows 8.
Specifications
Vertical System
Analog Channel 8
Input Impedance Resistance 1MΩ
Input Sensitivity 10mV/div to 5V/div
Input Coupling DC
Resolution 12 bits
Memory Depth 4K
Horizontal System
Max. Input 400V (DC+AC Peak)
Real-Time Sampling Rate 2.4MSa/s
Time Base Range 1ns/div to 20000s/div(1-2-5sequences)
Time Base Precision ±50ppm
Trigger System
Trigger Source CH1, CH2,CH3,CH4, CH5, CH6,CH7,CH8
Trigger Mode Edge
X-Y Mode
X-Axis Input CH1
Y-Axis Input CH2
Cursors and Measurement
Voltage Measurement Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase,Vavg, Vrms, Vcrms, Preshoot, Overshoot
Time Measurement Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle
Cursors Measurement Horizontal ,Vertical Track, Auto Measure Modes
Waveform Signal Process +, - , x, ÷, FFT, Invert
Voltage Range 10mV to 5V/div @ x 1 probe 100mV to 50V/div @ x 10 probe 10V to 5000V/div @ x 1000 probe 100V to 50000V/div @ x 10000 probe 200mV to 100V/div @ 20:1
Current Range 100mA to 50.0A/div @ CC65(20A) 1000mA to 500.0A/div @ CC65(65A) 1A to 100.0A/div @ CC650(60A) 10A to 1000.0A/div@ CC650(650A) 1A to 200.0A/div @CC1100(100A) 10A to 2000.0A/div @CC1100(1100A)
FFT Rectangular, Hanning, Hamming, Blackman Window
Math Addition, subtraction, multiplication, division
Programmable Generator
Channel 8
Output Level LVTTL
Frequency Range 0-250kHz
Interface USB 2.0
Power No need extra power supply
Package Weight 500g
Package Size 23 x 17 x 7.5cm
