Hall Research HR-101 Mic and Line-Level Fiber Optic Audio Extender Kit

The HR-101 a professional quality Fiber-Optic audio extender kit comprised of two units: a sender (HR-101-S) and a receiver (HR-101-R). The HR-101-S is a compact and professional grade microphone amplifier with stereo line-level mix that can be used as a stand-alone device or paired with the HR-101-R to extend audio over long distances on fiber optic cables. The HR-101-S provides a balanced mic input on an XLR connector as well as a stereo line level input on 3.5mm mini-stereo jack. The unit has an adjustable-gain low noise mic preamp with a gain range of +34 to +54 db (or x50 to x500) and provides indication of volume level on digital VU meter on its front panel (to prevent saturation and clipping due to too much gain). The unit accommodates a wide range of microphone types. Phantom power can be inserted by means of a front panel switch. The stereo line input is on a standard 3.5mm (1/8 inch) connector which gets mixed with the amplified microphone signal. In a typical application a presenter can hookup the audio from their PC to the line input and plug the mic to the XLR. The unit will mix the speakers voice with the PC audio. The HR-101-S has both stereo analog (on 3.5mm) and SPDIF digital (on RCA) outputs as well as a fiber-optic ST connector for driving long cables to 3,280 ft. to compatible receiver. The Model HR-101-R Receiver has an ST fiber optic input connector to receive audio from the sender. It provides a stereo line level output on 3.5mm mini-stereo jack and a SPDIF digital audio output on a RCA connector. The HR-101 can extend an audio over a single multi-mode fiber optic cable spanning distances of over 1000m (3280ft). For lengths of Up to 500 meters OM2 or OM3 cables are recommended and for distances of over 500 meters OM3 cable is recommended.
