HX 4S-A01 Battery Protection Board 4 Lithium Battery 14.8V Protection Board

HX 4S-A01 Battery Protection Board 4 Lithium Battery 14.8V Protection Board Specification: Item Type:Protection Board Model: HX-4S-A01 Size:72 X 17 X 3mm / 2.83 X 0.67 X 0.12in Overcharge Voltage Range: 4.25~4.35V Over-Discharge Voltage Range: 2.3~3.0V±0.05V Upper Limit Working Current: 6~8A Upper Limit Instantaneous Current: 12A Quiescent Current: Less Than 30μA Internal Resistance: Less Than 100m Ohm Charging Voltage: 16.8~17V Working Temperature: -40 degrees Celsius ~ 50 degrees Celsius Short Circuit Protection: Protection Charge Recovery Package List: 1 x Protection Board Note: P+ and P- are input and output. When combined the battery voltage capacity and internal resistance must be paired well. After the connection is completed the battery is charged with 16.8V voltage.
