HW-XC508 Microwave Induction Module Microwave Sensor Switch Frequency Module 5.8GHz 6-24V DC 12V 24V

Manual Click here to openProduct Overview XC508 is the latest dual board microwave induction module of the company Its appearance is exquisite the circuit structure of the product is simple and compact the performance is stable andcost effective and its cost performance is high especially suitable for other electronic appliances such as intelligent electrical appliances security products lighting products etc Secondary development of the field This product can be widely used in security monitoring intelligent control systems lighting appliances garages corridors roads etc Specification Model XC508Frequency Fixed frequency moduleInput voltage DC 6V 24V 300mAStatic power consumption 15mAOutput mode 5V with induction 0V without inductionTrigger mode repeatable triggerTransmission frequency 5 8GHZDelay time 2 120S potentiometer adjustable Induction distance 0 5 12m potentiometer adjustable Size 23 23 9mmRepeat trigger After the first trigger when the sensing area is triggered again the module delay time will be superimposed again when the first trigger time has not stopped For example the module delay time is 10S the induction signal is received again within 10S and then superimposed for 10S the uninterrupted trigger within 10S there will always be an output signal Working Principle According to the Doppler effect principle the XC508 microwave sensing module uses a plana antenna to transmit and receive high frequency electromagnetic w
