HTYSUPPLY 5/8 x 8-1/2 Wedge Anchor Zinc Plated (Box of 20)

ApplicationsThe anchor is made from Carbon Steel and is Zinc Plated. This anchor is designed for use in Concrete and should never be used in block or brick base material. EnvironmentThe anchor is designed for use in a Dry environment.Hole DiameterBit DiameterThe anchor requires a 58 hole to be drilled in the base material (Concrete ). The hole should be drilled with carbide tipped bit that meets ANSI standards and used in a hammer drill.Diameter of Anchor The diameter of the anchor is 58 .Length Anchor The length of the anchor is 8-12 Thread LengthThe length of the threads on the anchor is 4 in length.Minimum EmbedmentThe minimum anchor embedment into the concrete is 2-34 . Therefore the anchor must be installed so that a minimum of 2-34 of the anchor is embedded into the concrete. Fixture ThicknessThe fixture thickness or the thickness of the material being fastened for a anchor is 5-18 . This will ensure that the minimum embedment of 2-34 will be met.Fixture Hole DiameterThe hole in the fixture or material being fastened must be larger than the designated diameter of the anchor. The 58 diameter anchor requires the hole in the fixture to be 78 .Torque ValueTo be set properly in the concrete the anchor must be torqued to between 75 - 90 ft.lbs.Spacing between AnchorsEach anchor must be spaced a minimum distance of 6-14 from each other when measured center to center.Edge DistanceIt is very important not to install the anchor any closer than 3-18 from an unsupported edge of the concrete.
