HMC252 DC-3 GHz RF Single Pole Six Throw Switch RF Switch Non-reflective SP6T Switch Module

Feature HMC252AQS24E is a low cost non reflective SP6T switch in a 24 pin QSOP package with a broadband operating frequency range of DC to 3 0 GHz The switch provides single positive bias and true TTL CMOS compatibility The switch integrates a 3 6 decoder and only three control lines and a positive bias are needed to select each path HMC252AQS24E SP6T can replace SP4T and SPDT MMIC switches and multiple configurations of logic drivers Specification 1 Low insertion loss 2 GHz 1 0 dB2 Single positive power supply VDD 3V to 5V3 Integrated 3 6 TTL decoderApplication 1 Base station2 CATV DBS3 MMDS and wireless local area network4 Test equipmentPackage includes 1 x RF Switch
