HJC60 Weld Bead Height Welding Seam Gap Ruler Gage Metric Welding Gauge Inspection Measuring Tool

Descriptions The product mainly consists of a main ruler a height gauge an undercut depth gauge and a multi purpose gauge It is a welding inspection ruler used to detect various trough angles heights widths clearances and undercut depths of a weldment is applied to the detection of boilers bridges shipbuilding pressure vessels and oil field pipes and is also used to measure parts with higher requirements on welding qualit Features ◆ WS high quality welding gauge ◆ Made of stainless steel material sturdy and durable in use ◆ Laser engraving scales easy to read and wear resistant ◆ Highly polished Deburred everyside Easy operationSpecifications ◆ Material stainless steel◆ Scales Engraving Type Laser Engraving◆ Weight 230g◆ Size Show in the picture◆ Plastic box size L x W x H 117mm x 95mm x 24mm◆ Transition 1cm 10mm 0 39inch ◆ Measuring range Fillet Leg Length Throat Size 0 15mm Seam Reinforcement 0 15mm Undercut Pit Depth 0 5mm Seam Width 0 60mm Bevel Angle 80 150 degree Gap Width 0 5 6mm Package included 1 x HJC60 Weld Seam GaugeDetails picture
