HGLRC-Flipsky R-6374 190KV 3250W Brushless Sensored Motor Shaft 8mm for Electric Skateboard Rc Car

Description: Brand:HGLRC-Flipsky No:R-6374 Weight: 1.9 lb / 0.86 kg Packaging weight:1000g Packaging size:115mm*175mm*90mm Recommendation esc:3-12S 50A(HGLRC-Flipsky FSESC 4.12 50A SK8 ESC,click here;or HGLRC-FlipSky FSESC6.6,go to the link Mainly fit for 1/10 and 1/8 rc car,electric skateboard Motor Spec: Max Power: 3250 Watts Max Current: 85 Amps Max Volts: 12S Max Torque: 8Nm Motor Resistance: 0.05Ohm Recommend ESC: 3-12S 50A (FSESC4.12 50A or FSESC 6.6 60A) Battery type: 4-12S Diameter(mm): 63.4 Length(mm): 77 Total length (mm):102 SHAFT: Diameter 8mm, 30mm length, 3x1.5 keyway slot. Motor Wire: 130mm silicone 12AWG wire with 4.0mm Gold Bullet Connector Male. Wire configuration: Blue = A Black = B Yellow = C Stator: 0.2mm thickness lamination japan steel Magnet: N42SH high temp curve magnet Sensor Wire: Standard RC Sensor Wire JST-ZH 6pin 1.5mm pitch Internal PCB with 120 Degree Hall Effect Sensors. Motor can be used with or without a sensor. Sensorless operation is most common. VESC Sensor Wires required to use with VESC. Wire configuration: Red = 5v Blue = A Yellow = C Green = B Black = GND Screws(the packaging are not included): The screws used for the motor are M4x8mm metric bolts. Using our motor mounts, we recommend using M4x8mm Socket Cap bolts. Package included: 1X R-6374 190KV 3250W Motor
