HGLRC-Flipsky 6364 190KV 2650W Brushless Sensored Motor Shaft 8mm for Electric Skateboard Rc Models

Description: Brand:HGLRC-Flipsky No:6364,also name 6365,it is the same Weight: 1.23 lb / 0.56 kg Packaging weight:about 760g Packaging size:115mm*175mm*90mm Mainly fit for electric skateboards and electric bikes, as well as underwater propellers and robots Motor Spec: Max Power: 2650 Watts Motor KV:190KV Model Type: MP S-6364(also name 6365) Max Current: 65 Amps Max Volts: 12S Max Torque: 7Nm Motor Resistance: 0.05Ohm Recommend ESC: 3-12S 50A (FSESC4.12 50A or FSESC 6.6 60A) Battery type: 6-10S Diameter(mm): 63.4 Length(mm): 64 SHAFT: Diameter 8mm, 24mm length, 3x1.5 keyway slot. Motor Wire: 130mm silicone 12AWG wire with 4.0mm Gold Bullet Connector Female. Wire configuration: Blue = A Black = B Yellow = C Stator: 0.2mm thickness lamination japan steel Magnet: N42SH high temp curve magnet Sensor Wire: Standard RC Sensor Wire JST-ZH 6pin 1.5mm pitch Internal PCB with 120 Degree Hall Effect Sensors. Motor can be used with or without a sensor. Sensorless operation is most common. VESC Sensor Wires required to use with VESC. Wire configuration: Red = 5v White = Temp Blue = A Yellow = C Green = B Black = GND Screws(the packaging are not included): The screws used for the motor are M4x8mm metric bolts. Using our motor mounts, we recommend using M4x8mm Socket Cap bolts. Package included: 1X 6364 190KV 2650W Rc Car Motor((Fits 63mm Motor Mount))
