HDMI Splitter 1 in 4 Out Support 3D 4K x 2K HDCP EDID
Описание
Features
Simultaneously displays an Ultra Hi-Def source on up to four Ultra HD displays.
Supports resolutions up to Ultra HD 4K x 2K (3840 x 2160@60Hz YUV 4:2:0) and 1080p Full HD.
Supports four kinds of EDID handling abilities: mixed EDID, copy EDID, default 1080p output, default 4K x 2K output.
10.2Gbps bandwidth on each connection.
Support resolutions up to 4K, Full 3D, and 36 bit HDMI Deep Color.
Supports LPCM 7.1, Dolby True HD, Dolby Digital Plus and DTS-HD Master Audio.
Supports HDMI input/output cable 10 to 15 meters at 1080p/8-bit resolution.
HDCP compliant for compatibility with HDCP content protected devices, such as Blu-ray players, PS3, PC, STB, DVD, etc.
EDID Introduction
Mixed EDID: always follow the lowest resolution of the displays connected to the 4 outputs, in order to support all displays show the source.
Copy EDID: Output 4 is a prior port. When output 4 is connected to the display, all other displays connected to the other 3 outputs will follow the resolution of output 4. When output 4 is disconnected, all other 3 displays will output 1080p.
Default 1080p output: output a default 1080p source, in this case all outputs will display 1080p if they support resolution 1080p and above.
Default 4K x 2K output: output a default 4K x 2K source, in this case all outputs will display 4K x 2K if they support resolution 4K x 2K and above.
Specifications
Input ports 1 x HDMI(female)
Output ports 4 x HDMI output (female)
Bandwidth frequency 10.2Gbps
Resolution outputs up to 4K x 2K (3840 x 2160 @ 60Hz YUV 4:2:0)
Transmission distance 15m(Maximum)over standard HDMI cable/26 AWG
Dimension 11.5L x 6W x 2.5H cm
Weight 470g
Package included 1 x HDMI Splitter, 1 x Power Adapter, 1 x User Manual
Certification CE, FCC, RoHS
