HAYEAR FHD 34MP USB Industrial Electronic Digital Video Microscope Camera 130X 180X 300X C Mount Lens For Phone PCB Soldering

Noting: 1:PC Support : Windows XP/7/8/10 system 2:For USB output, the white balance, exposure and color adjustment are automatic, they can't be adjusted. For HDMI output, the functions can only be adjusted while connecting with monitor, if you connect the camera with computer, the functions also can not be adjusted. 3:When use USB connection, please make sure no TF card in the camera ,TF card storage is only for HDMI output. USB output will be storage in PC. 4:when connect the camera with computer, just plug the USB line is OK ( no need to use the power supply) Features: Model: Camera with HDMI USB2.0 two output Image format: jpg Image resolution: 34 MegaPixel Video format: MP4(for TF card) Video r ecorder: 2K@30FPS, 1080P@60FPS HDMI Video resolution: 1920*1080 @ 60FPS USB Video resolution: 1920*1080@30FPS; 1280*720@30FPS; 640*480@30FPS; 320*240@30FPS White Balance: Auto/Manual Light: Auto/Manual Exposure: Auto/Manual, value adjustable Color: Color Morror: Left/right,Up/Down Freeze: Support OSD: English/Chinese/French/Spanish/Japanese/German Line: different color,5 horizontal line 5 vertical line,any positions Specification: Image sensor: 34, 21, 16, 14 megapixel p anasonic CMOS sensor 1/2.33 inch Effective pixel: 34 megapixel Pixel size:1.335m 1.335m Frame rate:60fps Definition:FULL HD Housing:metal Lens:C/CS Video format: MOV Digital Zoom:Support Brightness control:Auto/manual Color:R/G/B adjustable Film and r ecord:Support Cross cursor:Support multi-color, size adjustable Transverse and vertical line: Support multi-color, 5 pcs of transverse lines/vertical lines, moveable Different color,5 horizontal line 5 vertical line,any positions TF card interface:Max 64G HDMI interface:Standard HDMI output (Type A) USB interface:Standard usb2.0 interface (Type B) Input Voltage: DC 12V 180X C-MOUNT Lens Working distance: 95mm Zoom c-mount Lens 0.5X C-mount adapter Zoom ratios: 6.5:1 Objective Magnification Power by 0.7 - 4.5X(about 10 - 180X on the display) Size: 180mm(L) * 50mm(DIA) (180x maximum working distance 16CM) 300X C-MOUNT Lens Working distance: 95mm Zoom c-mount Lens 1X C-mount adapter Zoom ratios: 6.5:1 Objective Magnification Power by 0.7 - 4.5X(about 10 - 300X on the display) Size: 248mm(L) * 50mm(DIA) (300x maximum working distance 11CM) 100X C-MOUNT Lens Magnification Power by 0.12 - 2X (about 8X - 100X on the display) Work distance: 100mm Visual field :2.4mm-32mm Size: 115mm(L) * 40mm(DIA) Weight: 210g 120X C-MOUNT Lens Magnification Power by 0.12 - 2X (about 8X - 100X on the display) Work distance: 250mm Visual field :2.4mm-32mm Weight: 100g 56 LED Adjustable Compact Microscope Ring Light Provides intense and focused shadow-free illumination 56 bright LED Lighting direction changeable Variable intensit y control Intense and focused shadow-free illumination 100,000 hours of life Power input: 100-240V, 50-60HZ, auto switching Inside diameter of the ring light: 1.0" (27mm) Overall outside diameter: 1.77" (45mm) Working Distance: 27mm-120mm Package including: 1 x Microscope Camera 1 x Power supply(EU NOTE:We will send you a plug adapter according to your country.) 1 x USB cable 1 x HDMI cable 1 x Software DISC 1 x Remote control Optional accessories incluede: 1 x C-MOUNT Lens(100X or 120X or 180X or 300X) 56 LED Adjustable Microscope Ring Light Details pictures:
