H3Y-4 Adjustable Time Relay 14 Pin LCD Digital Display DC 12V 24V AC 220V Dual Time Cycle Control Delayer With Base Fire

1111MicrosoftInternetExplorer402DocumentNotSpecified7 8 磅Normal0Specifications Manual Click here to openProduct Name Time Relay 14 Pin 4 Open 4 Close Model H3Y 4Voltage DC 12V 24V 220V optional Time Range 0 1s 99hTime Error 1 Power Consumption Max 1 5VAEnvironmental Temperature 25 75℃Allowable Voltage Range 90 110 of rated voltageWorking Modes Y Power On DelayC Delayed ReleaseX Loop DelayLc Number of Cyclic DelaysMode Setting Long press the S1 button on the left for 3 seconds and the mode will automatically switch in a loop after flashing Stop at the desired mode and release the button After 5 seconds it will stop flashing and save the setting Time Base Setting Long press the S2 button on the right for 3 seconds and the time base will automatically switch in a loop after flashing Stop at the desired mode and release the button After 5 seconds it will stop flashing and save the setting Number Setting Left click to switch modes Features 1 Fire Resistant and Heat Resistant Construction The time relay boasts a robust PC shell that is both fire resistant and heat resistant ensuring exceptional safety and durability This design choice provides reliable protection against environmental hazards making it suitable for various demanding applications 2 Clear LED Digital Display Equipped with a high definition LED screen the relay offers an intuitive and clear digital display panel This feature simplifies monitoring and setting adjustments providing u
