H.264 1080P 8CH CCTV Camera Standalone Security Super DVR SDVR (Adaptor: US)

Description :H.264 1080P 8CH CCTV Camera Standalone Super DVR SDVR Security System S-SDVR-9108IC is a latest 8CH SDVR-Super DVR. It combines 3 recording modes together, that is DVR Modes, NVR Modes, and HVR Modes(Hybrid DVR Modes). Under the DVR Modes, it's a Standards H.264 Full D1 DVR for all 8 Channels. Under the HVR Modes, it can supports 2CH D1 for Analog Cameras+(1*1080P+1*720P) for IP Cameras. Under the NVR Modes, it can be as a 4CH 720P NVR, 2CH 1080P NVR, 8CH 960H NVR(or 1CH*720P+7CH*D1 / 1CH*1080P+1CH*720P+2CH*D1) Specification : Model SDVR-9108IC System Main processor Industrial grade embedded micro controller chip Huawei HIS chipset Hi3520A Operating system Embedded LINUX operating system System resource Multi-channel real-time recording synchronously, multi-channel real-time playback, multi-channel multi-user network operation, USB back up. Display Operation interface 16 bit real color GUI interface support mouse operation Display screen (Take all analog input as an example, others are depended on the selected channel mode) 1/4 screen Video Video standard PAL(625 lines,50fps);NTSC(525lines,60fps) Image encode H.264(High Profile) Monitor quality Monitor:D1;VGA:1080P ;HDMI:1080P Playback quality Max support 1080P under HVR and NVR mode;Max support 4 x D1 under DVR mode: Encode capability 8CH D1 real time(DVR mode) Decode capability 8CH D1 real time(DVR mode) Multi-mode video input DVR mode: 8 *D1 HVR mode: 2 *D1+(1*1080P+1*720P) NVR mode: 8*960H / 4*720P / 2*1080P / 1*720P+7*D1 / 1*1080P+1*720P+2*D1 Motion detection Each channel can set 192(16*12)detection area;can set multi-level of flexibility (for local analog channel only) Audio Audio compression G.711A Record and playback Record mode Manual,alarm,motion detection,timing Local playback 1-9ch playback synchronously;Under the mode of DVR, Max support 8CH D1 real time playback synchronously Video search Time,date,event,channel search Storage and back up Space occupation Video:CIF 4~5G/day*channel, D1 16~20G/day*channel;audio:691.2M/day*channel Video storage Local HDD ,Network Back up mode Network backup,USB portable HDD,USB DVD-RW Interface Video input 8CH BNC Video output 1CH BNC,1CH VGA,1CH HDMI (1080P) Audio input 4CH RCA Audio output 1CH RCA Alarm input 1CH Alarm output 1CH Network port RJ45 10M/100M self-adaptive Ethernet port PTZ control 1 RS485;support multi kinds of PTZ Protocol USB port 2* USB2.0 HDD port 1 SATA(each max support 3072G) Wireless port 3G,WIFI(extension via USB port) other Support multi-browser(IE, Chrome,Firefox,Safari). Support all kinds of mobile monitor(iPhone,Windows Mobile,BlackBerry,Symbian, Android) Tour Yes Remote controller Yes Power 12V/2A Dimension 260(Length) x 234(Width) x 45(Height) Package included : 1 x 8CH CCTV Camera Super SDVR (No Include HDD) 1 x Power supply 1 x USB mouse 1 x CD Software 1 x HDMI cable
