Gupbes 1pc ADS1115 16-Bit I2C ADC Development Board Analog to Digital Converter Module ADC ADC Module

Features: For micro-controllers without an analog-to-digital converter or when you want a higher- ADC the ADS1115 provides 16-bit at 860 samples/second over I2C. The chip can be configured as 4 single-ended input channels or two differential channels. As a nice bonus it even includes a programmable gain up to x16 to help boost up smaller single/differential signals to the full range. We like this ADC because it can run from 2V to 5V power/logic can measure a large range of signals and its super easy to use. It is a great general purpose 16 bit converter. The chip s fairly small so it comes on a breakout board with ferrites to keep the AVDD and AGND quiet. Interfacing is done via I2C. The address can be changed to one of four options (see the data-sheet table 5) so you can have up to 4 ADS1115 s connected on a single 2-wire I2C bus for 16 single ended inputs. Four single-ended or two differential inputs. Programmable comparator; internal low-drift voltage reference; internal oscillator; internal PGA. This board/chip uses I2C 7-bit addresses between 0x48-0x4B selectable with jumpers. Specifications: Wide Supply Range: 2.0v to 5.5v; Low Current Consumption: Continuous Mode: Only 150uA Single-Shot Mode: Auto Shut-Down; Programmable Data Rate: 8sps to 860sps; I2C Interface: Pin-selectable addresses; Size: 2.8*1.8cm/1.1*0.7in Weight: 5g(approx.) Package Includes: 1 x Module 1 x Pin Header
