Goodhd 2/5Pcs 1.8 inch 128X160 TFT Full Color LCD Display SPI serial screen ST7735

Feature *Use our 1.8 -inch full -color TFT LCD screen module to upgrade the display and use the 128X160 resolution to make amazing visual effects. *Enjoy the flexibility of adjusting the direction of the screen to the horizontal or vertical direction. *Equipped with the ST7735 controller chip and supports 3.3V power supply our module is easy to use and installed. *Experience high contrast and extremely wide perspective to achieve the best display performance. *2PCS or 5PCS packet you have multiple substitutes watching time and money for a long time. Specification Size: 1.8 -inch TFT LCD Sub-defense rate: 128RGB*160 DOT-MATRIX Communication interface: SPI-4wire Interface Driving chip: ST7735S Color: full color Dimensions: 35.00 × 56 × 3.45 (mm) Show area: 28.03 (W)*35.04 (h) Pixel size: 0.219 (w)*0.219 (h) Working voltage: 3.3V Work current: 30mA Number of tube foot: 8pin (2.54mm spacing needle default is not welded) Perspective direction: 12 o clock direction Work temperature: -20 ~ 70 Module interface definition: 1 GD power supply 2 VOC power supply is Zheng 3.3V 3 SCL SPI clock line (docking with a single -chip microcomputer SPI_CLK) 4 SDA SPI data cable (single -sided hardware SPI_MOSL) 5 Res reset pipe foot 6 DC data order 7 CS SPI film selection 8 BL backlight control switch the default is not connected Package included 2/5*128x160 TFT FULL Color LCD Display Note: 1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2. Please allow slight manual measurement deviation for the data.
