Gigabyte Z590 AORUS ELITE AX ATX Motherboard with PCIe 4.0 and M.2
The Z590 AORUS ELITE AX comes with upgraded power solution, incredible cooling design, all PCIe 4.0 design and outstanding connectivity to elevate your gaming experience to the next level.Direct Power DesignZ590 AORUS ELITE AX motherboard uses an 12+1 phases digital CPU power design which includes both digital PWM Controller and DrMOS. These 100% digital controller and additional 8+4 Solid-pin CPU Power Connectors offer incredible precision in delivering power to the motherboard's most power-hungry and energy-sensitive components, allowing enthusiasts to get the absolute maximum performance from the new Intel 11th Gen CPU.12+1 Phases Digital Power Design• Cleaner and more efficient power delivery to the CPU with better thermal performance ensure stability under high CPU frequencies and heavy loading.
• Digital PWM Controller to deliver appropriate voltage to the CPU.
• Direct 12+1 Phases DrMOS without PWM Doublers, each power phase connects directly to the CPU, With capability to handle 720 Amps current in total.
• All-solid capacitors to improve Transient response and minimize oscillation.
• 8+4 Solid Pin CPU Power ConnectorsPower ArchitecturePower EfficiencyAdvanced Thermal SolutionZ590 AORUS ELITE AX uses high performance Full Covered thermal design with high coverage MOSFET Heatsinks and thick thermal pad, providing ultimate MOSFET cooling performance for enthusiasts, overclockers and gamers.Thermal DesignFully Covered Thermal DesignHigh coverage MOSFET and integrated molding Heatsinks to improve thermal efficiency with better airflow and heat exchange.LAIRD 5 W/mK Thermal PadBy using 1.5mm thicker 5 W/mK thermal conductivity pads, it can transfer 2.7x more heat compared to traditional thermal pads in the same time.2X M.2 Thermal GuardsBuilt-in M.2 heatsinks prevent high-speed, large capacity PCIe 4.0/3.0 SSDs from throttling due to overheating.Fully Covered MOSFET Heatsink2X Large SurfaceIncreased surface area up to 2X larger compared to traditional heatsinks. It improves heat dissipation from the MOSFETs.Real One-piece BuildTMOS is a TRUE single piece heatsink. Its one-piece design and larger surface drastically improve the cooling performance against competitors' multi-piece design.Multi-Cut DesignTMOS features several channels and inlets on the heatsink. This design allows for the air flow to go through which leads to a great improvement of the heat transfer performance.AORUS M.2 Thermal GuardGIGABYTE Ultra-Efficient M.2 Thermal GuardWith durability in mind, GIGABYTE provides a thermal solution for M.2 SSD devices. The M.2 Thermal Guard prevents throttling and bottlenecks from high speed M.2 SSDs as it helps to dissipate heat before it becomes an issue.Smart Fan 6Smart Fan 6 contains several unique cooling features that ensure gaming PC maintain its performance while staying cool and quiet. Multiple fan headers can support PWM/DC fan and pump, and users can easily define each fan curve based on different temperature sensors across the board via intuitive user interface.Headers & Sensors• 6 PWM/DC Fan Headers• 6 Internal Temperature SensorsCooling FeaturesHigh Current SupportEach fan headers support PWM and DC fan and Water cooling Pump , and up to 24W (12V x 2A) with Over-Current ProtectionPrecision ControlUp to 7 temperature/fan speed control points for precise fan curveDual Curve ModeSlope/Stair dual mode for different user scenarioFan StopFan can stop completely below users' specified temperature pointSmart Fan 6 BIOS UIImprove fan curve UIWe increase control points from 5 to 7 and larger fan speed graph for precise and easier fan curve control.Slope/Stair dual graph modeFan curve can be quickly switch with Slope and Stair modes for different user scenario. Slope is traditional and intuitive linear fan speed curve. With newly added Stair non-linear mode, fan keeps at same speed between specified temperature interval.Manual InputFor advanced users, we provide fan speed manual input for more precise control.EZ TuningUse can place 4 EZ Tuning points at rough temperature/fan speed, and Smart Fan 6 can quickly generate a fan curve.Fan curve profileFan curve profile can be saved in BIOS ROM, profile will be kept after updating BIOS.Intelligent Fan Control DesignFan StopAchieve fan silence. With Fan Stop, map any fan to stop completely when temperatures drop below a specified threshold. Which fan stops, based on readings from which sensor, and at what temperature-all of it can be customized to your liking.Unparalleled PerformanceWith the best quality components and GIGABYTE R&D design capability, the Z590 AORUS is a true beast among motherboards.XMP 5000+Support for DDR4 XMP Up to 5000MHz and BeyondAORUS is offering a tested and proven platform that ensures proper compatibility with profiles up to 5000MHz and beyond. All users need to do to attain this performance boost is to ensure that their memory module is XMP capable and that the XMP function is activated and enabled on their AORUS motherboard.PCIe 4.0 Hardware DesignPCIe 4.0 M.2 SlotM.2 PCIe 4.0 x4 slot with lower impedance.1 x PCIe 4.0 SlotReinforced PCIe 4.0 x 16.PCIe 4.0 Ready PCBPCIe 4.0 Ready Mid-Loss PCB.Triple PCIe 4.0/3.0 x4 M.2 Connectors with Thermal GuardAORUS Gaming Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their Systems' potential.Next Generation ConnectivityA high-end product needs to be future-proof so your system stays up-to-date with the latest technology. Z590 AORUS ELITE AX provides all next generation network, storage, and WIFI connectivity to keep you up to speed.First Adopter on 2.5GbE LAN Onboard2X Faster than ever• Adoption of 2.5G LAN provide up to 2.5 GbE network connectivity, with at least 2 times faster transfer speeds compared to general 1GbE networking, perfectly designed for gamers with ultimate online gaming experience.• Support Multi-Gig(10/100/1000/2500Mbps) RJ-45 ethernetIntel WiFi 6 802.11ax + BT 5 ModuleIntel Wireless solution supports 802.11ax, enables gigabit wireless performance, provides smooth video streaming, better gaming experience, few dropped connections and speeds up to 2.4Gbps. Moreover, Bluetooth 5 provides 4X range over BT 4.2 and with faster transmission.Benefit of WIFI 6• 5.5X throughput than 802.11ac 1x1• 4X better network capacity, no traffic jams especially in those dense area with lots of devices• Network efficiency increase for better user experience 3.2 Gen2x2 TYPE-CAMP-UP AudioHi-Res AudioHi-Res Audio certified, meaning that the product is capable of reproducing frequencies up to 40kHz or above which ensures user with the best audio quality at all times.Immersive Gaming ViBesRealtek High-End HD Audio CodecALC1220 120dB(A) SNR HD Audio with Smart Headphone Amp automatically detects impedance of your head-worn audio device, preventing issues such as low volume and distortion. With the new VB series audio controller, stream your voice to the world vibrantly with both front/rear microphone SNR up to 110/114dB(A).Definitive AestheticsZ590 AORUS ELITE AX features RGB FUSION 2.0 and offers users the option to control onboard, external light strips, and/or AORUS devices with RGB/ Addressable RGB LEDs to make their PC more unique and stylish.RGB Fusion
Multi-Zone Light Show DesignNow offering more LED customizations than ever, users can truly adapt their PC to represent their lifestyle. With full RGB support and a redesigned RGB Fusion 2.0 application, the user has complete control over the LEDs which surround the motherboard.RGB Fusion SoftwareWith an integrated intuitive user interface, the RGB Fusion 2.0 provides you a better solution for customizing the lighting effects across all supported devices. From motherboards, graphics cards to the peripheral products, you can personalize your gaming rig with your own style and show off your build by sharing the profiles. In addition, the new gaming mode makes the lighting effects interactive with selected games to bring you the most immersive gaming experience.GIGABYTE RGB Fusion APPDon't just make your PC shine, make it a work of art that friends will envy. With the GIGABYTE RGB Fusion mobile app users can watch as they control the lighting within their gaming PC. This gives users ease of access as they try and adjust colors and speeds for different modes, all this can be achieved away from the keyboard and monitor of their PC.Ultra DurableGIGABYTE is reputable for its product durability and high quality manufacturing process. Needless to say, we use the best components we can find for the Z590 AORUS motherboard and reinforce every slot to make each of them solid and durable.Q-Flash PlusUpdate the BIOS easily without installing the CPU, memory and graphics card.With GIGABYTE Q-Flash Plus, you don't need to install the CPU, memory and graphics card no
