Geekcreit® Signal Generator Module 35M-4.4GHz RF Signal Source Frequency Synthesizer ADF4351 Development Board

The Source code Click here to openSchematic Click here to openNote The on board signal source of the product can work normally no external signal source is required If you need an external signal source you can change the source code by yourself Source Code Click here to openHighlights With OLED displayHost computer USBserial portIntegrated key operationWide range voltage supplyGood man machine interfaceMany improvements on the phase noise phase spurious and loop filterMuch enhancement on the power filter and ground processingModule can achieve 35MHz 4 4GHz frequency output point frequency sweep frequency hopping and other basic functions Parameters Dimensions 88mm 67mmPower supply 5V 15V DC 5 1MM 5V USB Bandwidth ADF4351 35MHz 4 4GHz ADF4350 137MHz 4 4GHzModule step 100KHz min Frequency error ± 1KHzOutput OUTA OUTB two wayModule phase noise better than 100dBc 10KHz noise is different with different band phase Module output power 7dBm MAX Module interface The external communication port of the STM32 USB can be configured to USB or analog serial port in default Module program download mode SW module three wire system GND SWCLK SWDIO Packing includes 1 x Module1 x USB mini line1 x BNC male head to SMA male high frequency cable
