Gear Locking Tool Universal Camshaft Dual Cam Clamp Alignment Timing Belt Holder

Details: This universal kit covers most single overhead cam engines twin cam engines and quad cam engines lock camshafts to hold valve timing during belt replacement reduces repair prevents possible engine damage due to incorrect timing. Compact design to allow easy operation in small engine bays. Used to hold camshafts in position while changing timing belts on most over-head cam engines. Covers single cam twin cam and quad cam engines lock camshafts to hold valves in correct timing. Compact design to allow easy operation in small engine bays. Made carbon steel material high strength and durable. Includes essential lock tool parts it is very practical and save money for you. Specification: Material: Metal & Plastic Color: Red Size: as picture show Universal Fitment = Yse Instructions: 1. Rotate the engine to align the engine valve timing mark according to the vehicle manufacturer s instructions 2. Apply clamp (big clamp/single clamp) >Big clamp (double cam) 1. Loosen the two fixing bolts 2. Place large clamp between gears 3. Push away the sliding accessories 4. When meshing with the timing gear tighten the two bolts 5. Replace the belt according to the vehicle manufacturer s maintenance instructions 6. After completion loosen the two fixing bolts and remove the large clamp >Single clip (single double and four clips) 1. Find the position to clamp 2. Insert the clip under the cam gear and hook it at the end 3. Keep in place and tighten the locking bolt until it contacts with the cylinder head (do not over tighten) 4. When meshing with timing gear tighten two bolts 5. Replace the belt according to the vehicle manufacturer s maintenance instructions 6. After completion loosen the two fixing bolts and remove the clamp clamp (double cam) Package contents: 1 x Set of Cam Lock Tool Note: 1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2. Please allow slight manual measurement deviation for the data.
