Garage Remote Controller Low Power Consumption 12V 433MHz Wireless 4CH Transmitter Door Remote Relay Low Interference For Access Control

Garage Remote Controller Low Power Consumption 12V 433MHz Wireless 4CH Transmitter Door Remote Relay Low Interference for Access Control Specification: Item Type: Garage Remote Controller Material: Metal + ABS Seven Functions: Jog self-locking interlocking 2 way jog + 2 way self-locking 2 way jog + 2 way interlocking 2 way self-locking + 2 way interlocking independent 2 way interlocking + independent 2 way interlocking . Different modes can be set at the same time which is flexible and convenient. Battery Type: Button Battery included Battery Capacity: 120mAh Battery Model: CR2016 Transmitter: Channel: 4CH Remote Control Distance: 50 meters/164ft : Fixed welding Frequency: 433MHz Voltage: 6V Receiver: Decoding: Fixed welding Power Supply working voltage: DC 12V Relay: 12V DC Sensitivity: -105 dBm Working Temperature: -40?C-80?C Working Mode: Instantaneous switching self-locking interlocking change the style through the model pin the default is instantaneous Widely used in smart home lighting control remote control of access control systems garage doors wireless modification of doorbells wireless control of home appliance switches etc. Terminal Function Description: 1. +V?power positive input 2. GND?power negative input 3. 1?KC1 relay normally closed terminal 2?KC1 relay common terminal 3?KC1 relay normally open terminal 4. 4?KC3 relay normally closed end 5?KC3 relay common end 6?KC3 relay normally open end 5. 7?KC2 relay normally closed end 8?KC2 relay common end 9?KC2 relay normally open end 6. 10?KC4 relay normally closed end 11?KC4 relay common end 12?KC4 relay normally open end Learning : 1. Jog learning method: Press the matching button on the control panel once and the LED indicator will flash once. After the LED indicator lights up press the remote control button that needs to be coded. The control panel LED indicator flashes 3 times in succession and the matching is successful. 2. Self-locking learning method: Press the matching button on the control panel twice the LED indicator flashes 2 times. After the LED indicator lights up press the remote control button that needs to be coded and the control panel LED indicator flashes 3 times in succession. 3. Interlocking learning method: Press the control panel pairing button 3 times in succession the LED indicator flashes 3 times after the LED indicator lights up press the remote control button that needs to be paired the control panel LED indicator flashes 3 times in a row and the pairing is successful. 4. Two-way jog and two-way self-locking learning method: Press the matching button on the control panel 4 times the LED indicator flashes 4 times. After the LED indicator lights up press the remote control button that needs to be coded and the control panel LED indicator flashes 3 times in a row. The is successful. 5. Two-way jog and two-way interlocking learning method: Press the control panel pairing button 5 times in a row and the LED indicator will flash 5 times. After the LED indicator lights up press the remote control button that needs to be paired. The control panel LED indicator flashes 3 times in a row and the is successfully matched. 6. Two-way self-locking and two-way interlocking learning method: Press the matching button on the control panel 6 times
